3OAN | pdb_00003oan

Crystal structure of the Ran Binding Domain From The Nuclear Complex Component Nup2 From Ashbya Gossypii

• PDB DOI: https://doi.org/10.2210/pdb3OAN/pdb

• Classification: TRANSPORT PROTEIN
• Organism(s): Eremothecium gossypii
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): Yes


• Deposited: 2010-08-05 Released: 2010-08-18
• Deposition Author(s): Malashkevich, V.N., Toro, R., Sauder, J.M., Burley, S.K., Almo, S.C., New York SGX Research Center for Structural Genomics (NYSGXRC)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free:
  0.289 (Depositor), 0.272 (DCC)
• R-Value Work:
  0.209 (Depositor)
• R-Value Observed:
  0.213 (Depositor)

Literature

Crystal structure of the Ran Binding Domain From The Nuclear Complex Component Nup2 From Ashbya Gossypii

Malashkevich, V.N., Toro, R., Sauder, J.M., Burley, S.K., Almo, S.C.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 14.99 kDa
• Atom Count: 967
• Modeled Residue Count: 116
• Deposited Residue Count: 130
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
ABR034Wp	A	130	Eremothecium gossypii	Mutation(s): 1  Gene Names: ABR034W, AGOS_ABR034W
UniProt
Find proteins for Q75DJ0 (Eremothecium gossypii (strain ATCC 10895 / CBS 109.51 / FGSC 9923 / NRRL Y-1056)) Explore Q75DJ0  Go to UniProtKB:  Q75DJ0

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
GOL	B [auth A]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free:  0.289 (Depositor), 0.272 (DCC)
• R-Value Work:  0.209 (Depositor)
• R-Value Observed: 0.213 (Depositor)

Space Group: P 4₃ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 65.691	α = 90
b = 65.691	β = 90
c = 72.869	γ = 90

Software Package:

Software Name	Purpose
SCALEPACK	data scaling
REFMAC	refinement
PDB_EXTRACT	data extraction
CBASS	data collection
HKL-2000	data reduction
PHENIX	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2010-08-18
Deposition Author(s): Malashkevich, V.N., Toro, R., Sauder, J.M., Burley, S.K., Almo, S.C., New York SGX Research Center for Structural Genomics (NYSGXRC)

Revision History

• Version 1.0: 2010-08-18
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Version format compliance
• Version 1.2: 2018-11-21
  Changes: Data collection, Structure summary
• Version 1.3: 2021-02-10
  Changes: Database references, Derived calculations, Structure summary
• Version 1.4: 2024-11-27
  Changes: Data collection, Database references, Structure summary
