3O66 | pdb_00003o66

Crystal structure of glycine betaine/carnitine/choline ABC transporter

• PDB DOI: https://doi.org/10.2210/pdb3O66/pdb

• Classification: TRANSPORT PROTEIN
• Organism(s): Staphylococcus aureus subsp. aureus Mu50
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2010-07-28 Released: 2010-08-18
• Deposition Author(s): Chang, C., Bigelow, L., Carroll, J., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.86 Å
• R-Value Free:
  0.221 (Depositor), 0.220 (DCC)
• R-Value Work:
  0.176 (Depositor), 0.181 (DCC)
• R-Value Observed:
  0.178 (Depositor)

Literature

Crystal structure of glycine betaine/carnitine/choline ABC transporter

Chang, C., Bigelow, L., Carroll, J., Joachimiak, A.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 64.12 kDa
• Atom Count: 4,887
• Modelled Residue Count: 546
• Deposited Residue Count: 564
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Glycine betaine/carnitine/choline ABC transporter	A, B	282	Staphylococcus aureus subsp. aureus Mu50	Mutation(s): 0  Gene Names: opuCC, SAV2446
UniProt
Find proteins for A0A0H3K0Z1 (Staphylococcus aureus (strain Mu50 / ATCC 700699)) Explore A0A0H3K0Z1  Go to UniProtKB:  A0A0H3K0Z1

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PGE	C [auth A], E [auth B]	TRIETHYLENE GLYCOL C6 H14 O4 ZIBGPFATKBEMQZ-UHFFFAOYSA-N
ACT	D [auth A], F [auth B]	ACETATE ION C2 H3 O2 QTBSBXVTEAMEQO-UHFFFAOYSA-M

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.86 Å
• R-Value Free:  0.221 (Depositor), 0.220 (DCC)
• R-Value Work:  0.176 (Depositor), 0.181 (DCC)
• R-Value Observed: 0.178 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 53.192	α = 90
b = 114.039	β = 109.28
c = 55.887	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PDB_EXTRACT	data extraction
SBC-Collect	data collection
HKL-3000	data reduction
HKL-3000	data scaling
HKL-3000	phasing
SHELXD	phasing
SHELXE	model building
MLPHARE	phasing
DM	phasing
RESOLVE	phasing
Coot	model building
ARP/wARP	model building

Structure Validation

Entry History

Deposition Data

• Released Date: 2010-08-18
Deposition Author(s): Chang, C., Bigelow, L., Carroll, J., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Revision History

• Version 1.0: 2010-08-18
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Version format compliance
• Version 1.2: 2017-11-08
  Changes: Refinement description
• Version 1.3: 2024-11-27
  Changes: Data collection, Database references, Derived calculations, Structure summary
