3O43

Complex of an alpha/beta-peptide based on the gp41 CHR domain bound to gp41-5


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.285
  • R-Value Work: 0.193
  • R-Value Observed: 0.197

wwPDB Validation   3D Report Full Report


This is version 2.0 of the entry. See complete history


Literature

Broad Distribution of Energetically Important Contacts across an Extended Protein Interface.

Johnson, L.M.Horne, W.S.Gellman, S.H.

(2011) J Am Chem Soc 133: 10038-10041

  • DOI: https://doi.org/10.1021/ja203358t
  • Primary Citation of Related Structures:
    3O3X, 3O3Z, 3O40, 3O43

  • PubMed Abstract:

    Infection of cells by HIV depends upon profound structural rearrangements within the trimeric viral protein gp41. Critical to this process is the formation of a six-helix bundle in which a set of three N-terminal heptad repeat (NHR) helices assemble to form a core displaying long grooves that provide docking sites for three C-terminal heptad repeat (CHR) helices. We report experiments designed to discriminate between two alternative hypotheses regarding the source of affinity between individual CHR helices and the complementary groove: (1) affinity is dominated by interactions of a small cluster of side chains at one end of the CHR helix; or (2) affinity depends upon interactions distributed across the long CHR helix. We have employed two complementary experimental designs, and results from both favor the latter hypothesis.


  • Organizational Affiliation

    Department of Chemistry, University of Wisconsin, Madison, Wisconsin 53706, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
gp41-5198synthetic constructMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
alpha/beta-peptide derived from gp41 CHR domain sequence40N/AMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.285
  • R-Value Work: 0.193
  • R-Value Observed: 0.197
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 47.808α = 90
b = 57.621β = 90
c = 101.84γ = 90
Software Package:
Software NamePurpose
MD2data collection
PHASERphasing
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2011-07-27
    Type: Initial release
  • Version 1.1: 2011-11-23
    Changes: Structure summary
  • Version 1.2: 2023-09-06
    Changes: Data collection, Database references, Derived calculations, Refinement description
  • Version 2.0: 2023-11-15
    Changes: Atomic model, Data collection
