3NZU

Structure-based Optimization of Pyrazolo -Pyrimidine and -Pyridine Inhibitors of PI3-Kinase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.6 Å
  • R-Value Free: 0.240
  • R-Value Work: 0.213

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Structure-based optimization of pyrazolo-pyrimidine and -pyridine inhibitors of PI3-kinase.

Staben, S.T.Heffron, T.P.Sutherlin, D.P.Bhat, S.R.Castanedo, G.M.Chuckowree, I.S.Dotson, J.Folkes, A.J.Friedman, L.S.Lee, L.Lesnick, J.Lewis, C.Murray, J.M.Nonomiya, J.Olivero, A.G.Plise, E.Pang, J.Prior, W.W.Salphati, L.Rouge, L.Sampath, D.Tsui, V.Wan, N.C.Wang, S.Wiesmann, C.Wu, P.Zhu, B.Y.

(2010) Bioorg.Med.Chem.Lett. 20: 6048-6051

  • DOI: 10.1016/j.bmcl.2010.08.067
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Starting from HTS hit 1a, X-ray co-crystallization and molecular modeling were used to design potent and selective inhibitors of PI3-kinase. Bioavailablity in this series was improved through careful modulation of physicochemical properties. Compound ...

    Starting from HTS hit 1a, X-ray co-crystallization and molecular modeling were used to design potent and selective inhibitors of PI3-kinase. Bioavailablity in this series was improved through careful modulation of physicochemical properties. Compound 12 displayed in vivo knockdown of PI3K pharmacodynamic markers such as pAKT, pPRAS40, and pS6RP in a PC3 prostate cancer xenograft model.


    Organizational Affiliation

    Discovery Chemistry, Genentech, Inc., South San Francisco, CA 94080, USA. stevents@gene.com




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Phosphatidylinositol-4,5-bisphosphate 3-kinase catalytic subunit gamma isoform
A
954Homo sapiensMutation(s): 0
Gene Names: PIK3CG
EC: 2.7.1.153
Find proteins for P48736 (Homo sapiens)
Go to Gene View: PIK3CG
Go to UniProtKB:  P48736
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
NZU
Query on NZU

Download SDF File
Download CCD File
A
6-(2H-indazol-4-yl)-1-methyl-N-[3-(methylsulfonyl)propyl]-1H-pyrazolo[3,4-d]pyrimidin-4-amine
C17 H19 N7 O2 S
YZTXAMRYFBNCHP-UHFFFAOYSA-N
 Ligand Interaction
External Ligand Annotations
IDBinding Affinity (Sequence Identity %)
NZUIC50: 1.4 nM PDBBIND
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.6 Å
  • R-Value Free: 0.240
  • R-Value Work: 0.213
  • Space Group: C 1 2 1
Unit Cell:
Length (Å)Angle (°)
a = 144.004α = 90.00
b = 67.677β = 95.52
c = 106.362γ = 90.00
Software Package:
Software NamePurpose
PHENIXrefinement
DENZOdata reduction
PDB_EXTRACTdata extraction
SCALEPACKdata scaling
PHASERphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2010-12-29
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Version format compliance
