3NIT

The structure of UBR box (native1)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.6 Å
  • R-Value Free: 0.284
  • R-Value Work: 0.244

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Structural basis for the recognition of N-end rule substrates by the UBR box of ubiquitin ligases

Choi, W.S.Jeong, B.-C.Joo, Y.J.Lee, M.-R.Kim, J.Eck, M.J.Song, H.K.

(2010) Nat.Struct.Mol.Biol. 17: 1175-1181

  • DOI: 10.1038/nsmb.1907
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • The N-end rule pathway is a regulated proteolytic system that targets proteins containing destabilizing N-terminal residues (N-degrons) for ubiquitination and proteasomal degradation in eukaryotes. The N-degrons of type 1 substrates contain an N-term ...

    The N-end rule pathway is a regulated proteolytic system that targets proteins containing destabilizing N-terminal residues (N-degrons) for ubiquitination and proteasomal degradation in eukaryotes. The N-degrons of type 1 substrates contain an N-terminal basic residue that is recognized by the UBR box domain of the E3 ubiquitin ligase UBR1. We describe structures of the UBR box of Saccharomyces cerevisiae UBR1 alone and in complex with N-degron peptides, including that of the cohesin subunit Scc1, which is cleaved and targeted for degradation at the metaphase-anaphase transition. The structures reveal a previously unknown protein fold that is stabilized by a novel binuclear zinc center. N-terminal arginine, lysine or histidine side chains of the N-degron are coordinated in a multispecific binding pocket. Unexpectedly, the structures together with our in vitro biochemical and in vivo pulse-chase analyses reveal a previously unknown modulation of binding specificity by the residue at position 2 of the N-degron.


    Organizational Affiliation

    School of Life Sciences and Biotechnology, Korea University, Anam-Dong, Korea.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
E3 ubiquitin-protein ligase UBR1
A
90Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: UBR1 (PTR1)
EC: 2.3.2.27
Find proteins for P19812 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: UBR1
Go to UniProtKB:  P19812
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download SDF File
Download CCD File
A
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.6 Å
  • R-Value Free: 0.284
  • R-Value Work: 0.244
  • Space Group: P 65 2 2
Unit Cell:
Length (Å)Angle (°)
a = 39.207α = 90.00
b = 39.207β = 90.00
c = 274.689γ = 120.00
Software Package:
Software NamePurpose
DENZOdata reduction
PDB_EXTRACTdata extraction
HKL-2000data collection
SCALEPACKdata scaling
SOLVEphasing
HKL-2000data scaling
HKL-2000data reduction
REFMACrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2010-09-15
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Version format compliance
  • Version 1.2: 2017-11-08
    Type: Refinement description
