3NDY

The structure of the catalytic and carbohydrate binding domain of endoglucanase D from Clostridium cellulovorans


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.1 Å
  • R-Value Free: 0.195
  • R-Value Work: 0.147

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

The structure of the catalytic and carbohydrate binding domain of endoglucanase D

Bianchetti, C.M.Smith, R.W.Bingman, C.A.Phillips Jr., G.N.

To be published.

Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Endoglucanase D
A, B, C, D
345Clostridium cellulovorans (strain ATCC 35296 / DSM 3052 / OCM 3 / 743B)Mutation(s): 0
Gene Names: engD
EC: 3.2.1.4
Find proteins for P28623 (Clostridium cellulovorans (strain ATCC 35296 / DSM 3052 / OCM 3 / 743B))
Go to UniProtKB:  P28623
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Endoglucanase D
E, F, G, H
107Clostridium cellulovorans (strain ATCC 35296 / DSM 3052 / OCM 3 / 743B)Mutation(s): 0
Gene Names: engD
EC: 3.2.1.4
Find proteins for P28623 (Clostridium cellulovorans (strain ATCC 35296 / DSM 3052 / OCM 3 / 743B))
Go to UniProtKB:  P28623
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
BTB
Query on BTB

Download SDF File
Download CCD File
A, B, C, D
2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL
BIS-TRIS BUFFER
C8 H19 N O5
OWMVSZAMULFTJU-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.1 Å
  • R-Value Free: 0.195
  • R-Value Work: 0.147
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 85.297α = 90.00
b = 119.050β = 90.00
c = 198.487γ = 90.00
Software Package:
Software NamePurpose
PHENIXphasing
SCALEPACKdata scaling
DENZOdata reduction
PDB_EXTRACTdata extraction
PHENIXrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2010-09-08
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Version format compliance
