3N9B

Crystal Structure of the P. aeruginosa LigD phosphoesterase domain

• PDB DOI: https://doi.org/10.2210/pdb3N9B/pdb

• Classification: LIGASE
• Organism(s): Pseudomonas aeruginosa
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2010-05-28 Released: 2010-08-11
• Deposition Author(s): Shuman, S., Nair, P., Smith, P.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.92 Å
• R-Value Free: 0.199
• R-Value Work: 0.147
• R-Value Observed: 0.153

Literature

Structure of bacterial LigD 3'-phosphoesterase unveils a DNA repair superfamily

Nair, P.A., Smith, P., Shuman, S.

(2010) Proc Natl Acad Sci U S A 107: 12822-12827

• PubMed: 20616014
• DOI: https://doi.org/10.1073/pnas.1005830107
• Primary Citation of Related Structures:
  3N9B, 3N9D


• PubMed Abstract:


  The DNA ligase D (LigD) 3'-phosphoesterase (PE) module is a conserved component of the bacterial nonhomologous end-joining (NHEJ) apparatus that performs 3' end-healing reactions at DNA double-strand breaks. Here we report the 1.9 A crystal structure of Pseudomonas aeruginosa PE, which reveals that PE exemplifies a unique class of DNA repair enzyme. PE has a distinctive fold in which an eight stranded beta barrel with a hydrophobic interior supports a crescent-shaped hydrophilic active site on its outer surface. Six essential side chains coordinate manganese and a sulfate mimetic of the scissile phosphate. The PE active site and mechanism are unique vis à vis other end-healing enzymes. We find PE homologs in archaeal and eukaryal proteomes, signifying that PEs comprise a DNA repair superfamily.

---

Organizational Affiliation:

Molecular Biology Program, Sloan-Kettering Institute, New York, NY 10065, USA.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 39.94 kDa
• Atom Count: 2,915
• Modelled Residue Count: 305
• Deposited Residue Count: 342
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Probable ATP-dependent DNA ligase	A, B	171	Pseudomonas aeruginosa	Mutation(s): 0  Gene Names: LigD, PA2138
UniProt
Find proteins for Q9I1X7 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1)) Explore Q9I1X7  Go to UniProtKB:  Q9I1X7

Small Molecules

Ligands 5 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PEG	G [auth A]	DI(HYDROXYETHYL)ETHER C4 H10 O3 MTHSVFCYNBDYFN-UHFFFAOYSA-N
SO4	C [auth A], D [auth A], E [auth A], M [auth B]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L
YT3	I [auth A], J [auth A], K [auth A], L [auth A]	YTTRIUM (III) ION Y GRTBAGCGDOYUBE-UHFFFAOYSA-N
MN	H [auth A], N [auth B]	MANGANESE (II) ION Mn WAEMQWOKJMHJLA-UHFFFAOYSA-N
CL	F [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.92 Å
• R-Value Free: 0.199
• R-Value Work: 0.147
• R-Value Observed: 0.153
• Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 41.583	α = 102.32
b = 45.55	β = 109.43
c = 53.384	γ = 104.59

Software Package:

Software Name	Purpose
HKL-2000	data collection
SOLVE	phasing
PHENIX	refinement
HKL-2000	data reduction
SCALEPACK	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2010-08-11
Deposition Author(s): Shuman, S., Nair, P., Smith, P.

Revision History

• Version 1.0: 2010-08-11
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Version format compliance
• Version 1.2: 2024-02-21
  Changes: Data collection, Database references, Derived calculations
