3MW3 | pdb_00003mw3

Crystal structure of beta-neurexin 2 with the splice insert 4


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.33 Å
  • R-Value Free:
    0.252 (Depositor), 0.243 (DCC)
  • R-Value Work:
    0.191 (Depositor), 0.189 (DCC)
  • R-Value Observed:
    0.194 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 3MW3

This is version 2.3 of the entry. See complete history

Literature

Splice Form Dependence of beta-Neurexin/Neuroligin Binding Interactions.

Koehnke, J.Katsamba, P.S.Ahlsen, G.Bahna, F.Vendome, J.Honig, B.Shapiro, L.Jin, X.

(2010) Neuron 67: 61-74

  • DOI: https://doi.org/10.1016/j.neuron.2010.06.001
  • Primary Citation Related Structures:
    3MW2, 3MW3, 3MW4

  • PubMed Abstract:

    Alternatively spliced beta-neurexins (beta-NRXs) and neuroligins (NLs) are thought to have distinct extracellular binding affinities, potentially providing a beta-NRX/NL synaptic recognition code. We utilized surface plasmon resonance to measure binding affinities between all combinations of alternatively spliced beta-NRX 1-3 and NL 1-3 ectodomains. Binding was observed for all beta-NRX/NL pairs. The presence of the NL1 B splice insertion lowers beta-NRX binding affinity by approximately 2-fold, while beta-NRX splice insertion 4 has small effects that do not synergize with NL splicing. New structures of glycosylated beta-NRXs 1 and 2 containing splice insertion 4 reveal that the insertion forms a new beta strand that replaces the beta10 strand, leaving the NL binding site intact. This helps to explain the limited effect of splice insert 4 on NRX/NL binding affinities. These results provide new structural insights and quantitative binding information to help determine whether and how splice isoform choice plays a role in beta-NRX/NL-mediated synaptic recognition.


  • Organizational Affiliation
    • Department of Biochemistry and Molecular Biophysics, Columbia University, New York, NY 10032, USA.

Macromolecule Content

  • Total Structure Weight: 23.57 kDa
  • Atom Count: 1,650
  • Modeled Residue Count: 189
  • Deposited Residue Count: 208
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Neurexin-2-beta208Rattus norvegicusMutation(s): 1
Gene Names: Nrxn2
UniProt
Find proteins for Q63376 (Rattus norvegicus)
Explore Q63376
Go to UniProtKB:  Q63376
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ63376
Glycosylation
Glycosylation Sites: 1
Sequence Annotations
Expand
Reference Sequence

Oligosaccharides

Help
Entity ID: 2
MoleculeChains Length2D Diagram GlycosylationD Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-[beta-D-mannopyranose-(1-6)]2-acetamido-2-deoxy-beta-D-glucopyranose
B
3N-Glycosylation
Glycosylation Resources
GlyTouCan: G16421CZ
GlyCosmos: G16421CZ
GlyGen: G16421CZ

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.33 Å
  • R-Value Free:  0.252 (Depositor), 0.243 (DCC)
  • R-Value Work:  0.191 (Depositor), 0.189 (DCC)
  • R-Value Observed: 0.194 (Depositor)
Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 51.657α = 90
b = 102.087β = 90
c = 78.512γ = 90
Software Package:
Software NamePurpose
MAR345data collection
PHASERphasing
REFMACrefinement
HKL-2000data reduction
SCALEPACKdata scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2010-07-28
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Advisory, Version format compliance
  • Version 1.2: 2017-11-08
    Changes: Advisory, Refinement description
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Atomic model, Data collection, Database references, Derived calculations, Structure summary
  • Version 2.1: 2021-10-06
    Changes: Advisory, Database references, Structure summary
  • Version 2.2: 2023-09-06
    Changes: Data collection, Refinement description
  • Version 2.3: 2024-11-06
    Changes: Structure summary
