3MUQ | pdb_00003muq

The crystal structure of a conserved functionally unknown protein from Vibrio parahaemolyticus RIMD 2210633

PDB DOI: https://doi.org/10.2210/pdb3MUQ/pdb

Classification: structural genomics, unknown function
Organism(s): Vibrio parahaemolyticus RIMD 2210633
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2010-05-03 Released: 2010-05-12
Deposition Author(s): Tan, K., Wu, R., Bearden, J., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.05 Å
R-Value Free:
0.207 (Depositor), 0.207 (DCC)
R-Value Work:
0.164 (Depositor), 0.167 (DCC)
R-Value Observed:
0.166 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3MUQ

This is version 1.2 of the entry. See complete history.

Literature

The crystal structure of a conserved functionally unknown protein from Vibrio parahaemolyticus RIMD 2210633

Tan, K., Wu, R., Bearden, J., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 53.5 kDa
Atom Count: 3,982
Modeled Residue Count: 466
Deposited Residue Count: 474
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
uncharacterized conserved protein	A, B	237	Vibrio parahaemolyticus RIMD 2210633	Mutation(s): 0 Gene Names: VP1501
UniProt
Find proteins for Q87PK2 (Vibrio parahaemolyticus serotype O3:K6 (strain RIMD 2210633)) Explore Q87PK2 Go to UniProtKB: Q87PK2
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q87PK2
Sequence Annotations Expand
Reference Sequence

Small Molecules

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.05 Å
R-Value Free: 0.207 (Depositor), 0.207 (DCC)
R-Value Work: 0.164 (Depositor), 0.167 (DCC)
R-Value Observed: 0.166 (Depositor)

Space Group: P 2₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 107.075	α = 90
b = 109.088	β = 90
c = 51.665	γ = 90

Software Package:

Software Name	Purpose
SBC-Collect	data collection
SHELXD	phasing
MLPHARE	phasing
DM	model building
ARP	model building
WARP	model building
HKL-3000	phasing
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling
DM	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2010-05-12

Deposition Author(s):

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2010-05-12
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2024-11-27
Changes: Data collection, Database references, Derived calculations, Structure summary
