3MTJ | pdb_00003mtj

The Crystal Structure of a Homoserine Dehydrogenase from Thiobacillus denitrificans to 2.15A

PDB DOI: https://doi.org/10.2210/pdb3MTJ/pdb

Classification: OXIDOREDUCTASE
Organism(s): Thiobacillus denitrificans ATCC 25259
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2010-04-30 Released: 2010-05-12
Deposition Author(s): Stein, A.J., Cui, H., Chin, S., Savchenko, A., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.15 Å
R-Value Free:
0.256 (Depositor), 0.252 (DCC)
R-Value Work:
0.217 (Depositor), 0.216 (DCC)
R-Value Observed:
0.219 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3MTJ

This is version 1.3 of the entry. See complete history.

Literature

The Crystal Structure of a Homoserine Dehydrogenase from Thiobacillus denitrificans to 2.15A

Stein, A.J., Cui, H., Chin, S., Savchenko, A., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 48.68 kDa
Atom Count: 3,338
Modeled Residue Count: 431
Deposited Residue Count: 444
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Homoserine dehydrogenase	A	444	Thiobacillus denitrificans ATCC 25259	Mutation(s): 0 Gene Names: Tbd_0843 EC: 1.1.1.3
UniProt
Find proteins for Q3SKI5 (Thiobacillus denitrificans (strain ATCC 25259 / T1)) Explore Q3SKI5 Go to UniProtKB: Q3SKI5
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q3SKI5
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain C [auth A] SDF format, chain B [auth A] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] MOL2 format, chain B [auth A] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A] mmCIF format, chain B [auth A]	B [auth A], C [auth A], D [auth A]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.15 Å
R-Value Free: 0.256 (Depositor), 0.252 (DCC)
R-Value Work: 0.217 (Depositor), 0.216 (DCC)
R-Value Observed: 0.219 (Depositor)

Space Group: P 4₂ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 67.613	α = 90
b = 67.613	β = 90
c = 224.279	γ = 90

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
REFMAC	refinement
PDB_EXTRACT	data extraction
SBC-Collect	data collection
HKL-3000	data reduction
HKL-3000	data scaling
SHELX	phasing
MLPHARE	phasing
DM	phasing
ARP/wARP	model building
Coot	model building

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2010-05-12

Deposition Author(s):

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2010-05-12
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2017-11-08
Changes: Refinement description
Version 1.3: 2024-11-06
Changes: Data collection, Database references, Derived calculations, Structure summary
