3MGL | pdb_00003mgl

Crystal structure of permease family protein from Vibrio cholerae

• PDB DOI: https://doi.org/10.2210/pdb3MGL/pdb

• Classification: TRANSPORT PROTEIN
• Organism(s): Vibrio cholerae O1 biovar El Tor str. N16961
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2010-04-06 Released: 2010-04-21
• Deposition Author(s): Chang, C., Marshall, N., Bearden, J., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.25 Å
• R-Value Free:
  0.247 (Depositor), 0.251 (DCC)
• R-Value Work:
  0.193 (Depositor), 0.231 (DCC)
• R-Value Observed:
  0.196 (Depositor)

Literature

Crystal structure of permease family protein from Vibrio cholerae

Chang, C., Marshall, N., Bearden, J., Joachimiak, A.

To be published.

Biological Assembly 1

Global Symmetry: Dihedral - D4  (Explore in 3D)
Global Stoichiometry: Homo 8-mer - A8

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 30.59 kDa
• Atom Count: 2,065
• Modeled Residue Count: 254
• Deposited Residue Count: 260
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Sulfate permease family protein	A, B	130	Vibrio cholerae O1 biovar El Tor str. N16961	Mutation(s): 0  Gene Names: VC_A0077
UniProt
Find proteins for Q9KN88 (Vibrio cholerae serotype O1 (strain ATCC 39315 / El Tor Inaba N16961)) Explore Q9KN88  Go to UniProtKB:  Q9KN88

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
IOD	C [auth A], D [auth A], E [auth A], F [auth A], G [auth A], H [auth A], I [auth B], J [auth B], K [auth B], L [auth B], M [auth B]	IODIDE ION I XMBWDFGMSWQBCA-UHFFFAOYSA-M

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.25 Å
• R-Value Free:  0.247 (Depositor), 0.251 (DCC)
• R-Value Work:  0.193 (Depositor), 0.231 (DCC)
• R-Value Observed: 0.196 (Depositor)

Space Group: P 4 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 90.914	α = 90
b = 90.914	β = 90
c = 65.21	γ = 90

Software Package:

Software Name	Purpose
SBC-Collect	data collection
HKL-3000	phasing
SHELXD	phasing
SHELXE	model building
MLPHARE	phasing
DM	model building
RESOLVE	model building
Coot	model building
ARP/wARP	model building
REFMAC	refinement
HKL-3000	data reduction
HKL-3000	data scaling
DM	phasing
RESOLVE	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2010-04-21
Deposition Author(s): Chang, C., Marshall, N., Bearden, J., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Revision History

• Version 1.0: 2010-04-21
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Version format compliance
• Version 1.2: 2017-11-08
  Changes: Refinement description
• Version 1.3: 2024-10-16
  Changes: Data collection, Database references, Derived calculations, Structure summary
