3MF4

Crystal structure of putative two-component system response regulator/ggdef domain protein

• PDB DOI: https://doi.org/10.2210/pdb3MF4/pdb

• Classification: SIGNALING PROTEIN
• Organism(s): Aeromonas salmonicida subsp. salmonicida A449
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): Yes


• Deposited: 2010-04-01 Released: 2010-04-14
• Deposition Author(s): Malashkevich, V.N., Toro, R., Sauder, J.M., Burley, S.K., Almo, S.C., New York SGX Research Center for Structural Genomics (NYSGXRC)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free: 0.273
• R-Value Work: 0.222
• R-Value Observed: 0.224

Literature

Crystal structure of putative two-component system response regulator/ggdef domain protein

Malashkevich, V.N., Toro, R., Sauder, J.M., Burley, S.K., Almo, S.C.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 59.82 kDa
• Atom Count: 4,221
• Modelled Residue Count: 491
• Deposited Residue Count: 518
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Two-component system response regulator/GGDEF domain protein	A, B	259	Aeromonas salmonicida subsp. salmonicida A449	Mutation(s): 4  Gene Names: ASA_2441
UniProt
Find proteins for A4SNL2 (Aeromonas salmonicida (strain A449)) Explore A4SNL2  Go to UniProtKB:  A4SNL2

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
MG	C [auth A], D [auth A], E [auth B], F [auth B]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free: 0.273
• R-Value Work: 0.222
• R-Value Observed: 0.224
• Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 40.919	α = 61.95
b = 53.269	β = 81.09
c = 57.908	γ = 78.76

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
PHASER	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction

Structure Validation

Entry History

Deposition Data

• Released Date: 2010-04-14
Deposition Author(s): Malashkevich, V.N., Toro, R., Sauder, J.M., Burley, S.K., Almo, S.C., New York SGX Research Center for Structural Genomics (NYSGXRC)

Revision History

• Version 1.0: 2010-04-14
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Advisory, Refinement description, Version format compliance
• Version 1.2: 2017-11-08
  Changes: Refinement description
• Version 1.3: 2018-11-21
  Changes: Data collection, Structure summary
• Version 1.4: 2021-02-10
  Changes: Database references, Derived calculations, Structure summary
• Version 1.5: 2021-10-06
  Changes: Database references
• Version 1.6: 2023-09-06
  Changes: Data collection, Refinement description
• Version 1.7: 2023-11-22
  Changes: Data collection
