3M8M

1.05 A Structure of Manganese-free Manganese Peroxidase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.05 Å
  • R-Value Free: 0.139
  • R-Value Work: 0.117

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Ultrahigh (0.93A) resolution structure of manganese peroxidase from Phanerochaete chrysosporium: implications for the catalytic mechanism.

Sundaramoorthy, M.Gold, M.H.Poulos, T.L.

(2010) J.Inorg.Biochem. 104: 683-690

  • DOI: 10.1016/j.jinorgbio.2010.02.011
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Manganese peroxidase (MnP) is an extracellular heme enzyme produced by the lignin-degrading white-rot fungus Phanerochaete chrysosporium. MnP catalyzes the peroxide-dependent oxidation of Mn(II) to Mn(III). The Mn(III) is released from the enzyme in ...

    Manganese peroxidase (MnP) is an extracellular heme enzyme produced by the lignin-degrading white-rot fungus Phanerochaete chrysosporium. MnP catalyzes the peroxide-dependent oxidation of Mn(II) to Mn(III). The Mn(III) is released from the enzyme in complex with oxalate, enabling the oxalate-Mn(III) complex to serve as a diffusible redox mediator capable of oxidizing lignin, especially under the mediation of unsaturated fatty acids. One heme propionate and the side chains of Glu35, Glu39 and Asp179 have been identified as Mn(II) ligands in our previous crystal structures of native MnP. In our current work, new 0.93A and 1.05A crystal structures of MnP with and without bound Mn(II), respectively, have been solved. This represents only the sixth structure of a protein of this size at 0.93A resolution. In addition, this is the first structure of a heme peroxidase from a eukaryotic organism at sub-Angstrom resolution. These new structures reveal an ordering/disordering of the C-terminal loop, which is likely required for Mn binding and release. In addition, the catalytic Arg42 residue at the active site, normally thought to function only in the peroxide activation process, also undergoes ordering/disordering that is coupled to a transient H-bond with the Mn ligand, Glu39. Finally, these high-resolution structures also reveal the exact H atoms in several parts of the structure that are relevant to the catalytic mechanism.


    Related Citations:
    • High-resolution crystal structure of manganese peroxidase: substrate and inhibitor complexes.
      Sundaramoorthy, M.,Youngs, H.L.,Gold, M.H.,Poulos, T.L.
      (2005) Biochemistry 44: 6463
    • The crystal structure of manganese peroxidase from Phanerochaete chrysosporium at 2.06-A resolution.
      Sundaramoorthy, M.,Kishi, K.,Gold, M.H.,Poulos, T.L.
      (1994) J.Biol.Chem. 269: 32759


    Organizational Affiliation

    Department of Biochemistry, Vanderbilt University Medical Center, Nashville, TN 37232, United States.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Manganese peroxidase 1
A
357Phanerochaete chrysosporiumMutation(s): 0
Gene Names: MNP1
EC: 1.11.1.13
Find proteins for Q02567 (Phanerochaete chrysosporium)
Go to UniProtKB:  Q02567
Small Molecules
Ligands 5 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
GOL
Query on GOL

Download SDF File
Download CCD File
A
GLYCEROL
GLYCERIN; PROPANE-1,2,3-TRIOL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
CA
Query on CA

Download SDF File
Download CCD File
A
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
 Ligand Interaction
MAN
Query on MAN

Download SDF File
Download CCD File
A
ALPHA-D-MANNOSE
C6 H12 O6
WQZGKKKJIJFFOK-PQMKYFCFSA-N
 Ligand Interaction
HEM
Query on HEM

Download SDF File
Download CCD File
A
PROTOPORPHYRIN IX CONTAINING FE
HEME
C34 H32 Fe N4 O4
KABFMIBPWCXCRK-RGGAHWMASA-L
 Ligand Interaction
NAG
Query on NAG

Download SDF File
Download CCD File
A
N-ACETYL-D-GLUCOSAMINE
C8 H15 N O6
OVRNDRQMDRJTHS-FMDGEEDCSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.05 Å
  • R-Value Free: 0.139
  • R-Value Work: 0.117
  • Space Group: C 1 2 1
Unit Cell:
Length (Å)Angle (°)
a = 160.570α = 90.00
b = 45.300β = 97.31
c = 52.830γ = 90.00
Software Package:
Software NamePurpose
SHELXrefinement
SHELXL-97refinement
SCALAdata scaling
MAR345dtbdata collection
MOSFLMdata reduction
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2010-04-14
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Version format compliance
  • Version 1.2: 2017-11-08
    Type: Refinement description
