3LHN | pdb_00003lhn

Crystal structure of putative lipoprotein (NP_718719.1) from Shewanella oneidensis at 1.42 A resolution

• PDB DOI: https://doi.org/10.2210/pdb3LHN/pdb

• Classification: LIPID BINDING PROTEIN
• Organism(s): Shewanella oneidensis
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2010-01-22 Released: 2010-02-23
• Deposition Author(s): Joint Center for Structural Genomics (JCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.42 Å
• R-Value Free:
  0.181 (Depositor), 0.190 (DCC)
• R-Value Work:
  0.172 (Depositor), 0.180 (DCC)
• R-Value Observed:
  0.173 (Depositor)

Literature

Crystal structure of putative lipoprotein (NP_718719.1) from Shewanella oneidensis at 1.42 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Biological Assembly 1

Global Symmetry: Dihedral - D2  (Explore in 3D)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 2 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 27.38 kDa
• Atom Count: 2,114
• Modeled Residue Count: 215
• Deposited Residue Count: 252
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Lipoprotein	A, B	126	Shewanella oneidensis	Mutation(s): 0  Gene Names: SO_3163
UniProt
Find proteins for Q8ECH9 (Shewanella oneidensis (strain ATCC 700550 / JCM 31522 / CIP 106686 / LMG 19005 / NCIMB 14063 / MR-1)) Explore Q8ECH9  Go to UniProtKB:  Q8ECH9

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
SO4	C [auth A]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L
GOL	D [auth A], E [auth B]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.42 Å
• R-Value Free:  0.181 (Depositor), 0.190 (DCC)
• R-Value Work:  0.172 (Depositor), 0.180 (DCC)
• R-Value Observed: 0.173 (Depositor)

Space Group: P 6₁ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 50.185	α = 90
b = 50.185	β = 90
c = 300.508	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement
PHENIX	refinement
SOLVE	phasing
MolProbity	model building
XSCALE	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction

Structure Validation

Entry History

Deposition Data

• Released Date: 2010-02-23
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Revision History

• Version 1.0: 2010-02-23
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Advisory, Version format compliance
• Version 1.2: 2017-10-25
  Changes: Author supporting evidence, Refinement description
• Version 1.3: 2019-07-17
  Changes: Data collection, Derived calculations, Refinement description
• Version 1.4: 2023-02-01
  Changes: Database references, Derived calculations
• Version 1.5: 2024-10-16
  Changes: Data collection, Structure summary
