3LGE

Crystal structure of rabbit muscle aldolase-SNX9 LC4 complex


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.189
  • R-Value Work: 0.151
  • R-Value Observed: 0.153

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Mechanism of aldolase control of sorting nexin 9 function in endocytosis.

Rangarajan, E.S.Park, H.Fortin, E.Sygusch, J.Izard, T.

(2010) J Biol Chem 285: 11983-11990

  • DOI: 10.1074/jbc.M109.092049
  • Primary Citation of Related Structures:
    3LGE

  • PubMed Abstract:
  • Sorting nexin 9 (SNX9) functions in a complex with the GTPase dynamin-2 at clathrin-coated pits, where it provokes fission of vesicles to complete endocytosis. Here the SNX9.dynamin-2 complex binds to clathrin and adapter protein complex 2 (AP-2) tha ...

    Sorting nexin 9 (SNX9) functions in a complex with the GTPase dynamin-2 at clathrin-coated pits, where it provokes fission of vesicles to complete endocytosis. Here the SNX9.dynamin-2 complex binds to clathrin and adapter protein complex 2 (AP-2) that line these pits, and this occurs through interactions of the low complexity domain (LC4) of SNX9 with AP-2. Intriguingly, localization of the SNX9.dynamin-2 complex to clathrin-coated pits is blocked by interactions with the abundant glycolytic enzyme aldolase, which also binds to the LC4 domain of SNX9. The crystal structure of the LC4 motif of human SNX9 in complex with aldolase explains the biochemistry and biology of this interaction, where SNX9 binds near the active site of aldolase via residues 165-171 that are also required for the interactions of SNX9 with AP-2. Accordingly, SNX9 binding to aldolase is structurally precluded by the binding of substrate to the active site. Interactions of SNX9 with aldolase are far more extensive and differ from those of the actin-nucleating factor WASP with aldolase, indicating considerable plasticity in mechanisms that direct the functions of the aldolase as a scaffold protein.


    Organizational Affiliation

    Department of Cancer Biology, The Scripps Research Institute, Jupiter, Florida 33458, USA.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Fructose-bisphosphate aldolase AABCD363Oryctolagus cuniculusMutation(s): 0
Gene Names: ALDOA
EC: 4.1.2.13
Find proteins for P00883 (Oryctolagus cuniculus)
Explore P00883
Go to UniProtKB:  P00883
Protein Feature View
Expand
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
Sorting nexin-9EFGH31N/AMutation(s): 0
Find proteins for Q9Y5X1 (Homo sapiens)
Explore Q9Y5X1
Go to UniProtKB:  Q9Y5X1
NIH Common Fund Data Resources
PHAROS  Q9Y5X1
Protein Feature View
Expand
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.189
  • R-Value Work: 0.151
  • R-Value Observed: 0.153
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 87.028α = 90
b = 118.175β = 90
c = 175.896γ = 90
Software Package:
Software NamePurpose
BUSTERrefinement
SCALEPACKdata scaling
MOLREPphasing
TNTrefinement
PDB_EXTRACTdata extraction
HKL-2000data reduction
DENZOdata reduction

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 2010-02-02
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2017-11-01
    Changes: Refinement description
  • Version 1.3: 2019-07-17
    Changes: Data collection, Refinement description
