3LAK

Crystal structure of HIV-1 reverse transcriptase in complex with N1-heterocycle pyrimidinedione non-nucleoside inhibitor

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.274
  • R-Value Work: 0.223
  • R-Value Observed: 0.226

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history.


Literature

N1-Heterocyclic pyrimidinediones as non-nucleoside inhibitors of HIV-1 reverse transcriptase.

Mitchell, M.L., Son, J.C., Lee, I.Y., Lee, C.K., Kim, H.S., Guo, H., Wang, J., Hayes, J., Wang, M., Paul, A., Lansdon, E.B., Chen, J.M., Eisenberg, G., Geleziunas, R., Xu, L., Kim, C.U.

(2010) Bioorg Med Chem Lett 20: 1585-1588

  • DOI: 10.1016/j.bmcl.2010.01.086
  • Primary Citation of Related Structures:
    3LAK

  • PubMed Abstract:

    • A series of N1-heterocyclic pyrimidinediones were extensively evaluated as HIV-1 non-nucleoside reverse transcriptase inhibitors (NNRTIs). Inhibitor 1 is active against NNRTI-resistant viruses including RT mutant K103N. The co-crystal structure of inhibitor 1 with HIV-1 RT revealed that H-bonds are formed with K101 and K103 ...

    A series of N1-heterocyclic pyrimidinediones were extensively evaluated as HIV-1 non-nucleoside reverse transcriptase inhibitors (NNRTIs). Inhibitor 1 is active against NNRTI-resistant viruses including RT mutant K103N. The co-crystal structure of inhibitor 1 with HIV-1 RT revealed that H-bonds are formed with K101 and K103. Efforts to improve the suboptimal pharmacokinetic profile of 1 resulted in the discovery of compound 13, which represents the lead compound in this series with improved pharmacokinetics and similar potency as inhibitor 1.

    Organizational Affiliation:

    Gilead Sciences, Inc., 333 Lakeside Drive, Foster City, CA 94404, USA. mmitchell@gilead.com



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
HIV Reverse transcriptaseA, B560HIV-1 M:B_HXB2RMutation(s): 0
Gene Names: gag-pol
EC: 2.7.7.49 (PDB Primary Data), 3.4.23.16 (UniProt), 2.7.7.7 (UniProt), 3.1.26.13 (UniProt), 3.1.13.2 (UniProt), 2.7.7 (UniProt), 3.1 (UniProt)
UniProt
Find proteins for P04585 (Human immunodeficiency virus type 1 group M subtype B (isolate HXB2))
Explore P04585
Go to UniProtKB:  P04585
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP04585
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
KR1
Query on KR1
Download Ideal Coordinates CCD File
C [auth A]3-({3-[(2-amino-6-fluoropyridin-4-yl)methyl]-5-(1-methylethyl)-2,6-dioxo-1,2,3,6-tetrahydropyrimidin-4-yl}carbonyl)-5-methylbenzonitrile
C22 H20 F N5 O3
SORPAQIMHXALKW-UHFFFAOYSA-N		 Ligand Interaction
SO4
Query on SO4
Download Ideal Coordinates CCD File
D [auth A],
E [auth A],
F [auth A],
G [auth A]		SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L		 Ligand Interaction
CL
Query on CL
Download Ideal Coordinates CCD File
H [auth B]CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M		 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.274
  • R-Value Work: 0.223
  • R-Value Observed: 0.226
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 118.025α = 90
b = 154.603β = 90
c = 154.478γ = 90
Software Package:
Software NamePurpose
BOSdata collection
EPMRphasing
CNXrefinement
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


View more in-depth experimental data

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2010-02-23
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
