3L09 | pdb_00003l09

Crystal structure of Putative transcriptional regulator (JANN_22DEC04_CONTIG27_REVISED_GENE3569) from Jannaschia sp. CCS1 at 2.81 A resolution

PDB DOI: https://doi.org/10.2210/pdb3L09/pdb

Classification: Transcription regulator
Organism(s): Jannaschia sp. CCS1
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2009-12-09 Released: 2010-01-12
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.81 Å
R-Value Free:
0.245 (Depositor), 0.260 (DCC)
R-Value Work:
0.199 (Depositor), 0.210 (DCC)
R-Value Observed:
0.202 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 1.5 of the entry. See complete history.

Literature

Crystal structure of Putative transcriptional regulator (JANN_22DEC04_CONTIG27_REVISED_GENE3569) from Jannaschia sp. CCS1 at 2.81 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 116.46 kDa
Atom Count: 7,745
Modeled Residue Count: 1,005
Deposited Residue Count: 1,064
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative transcriptional regulator	A, B, C, D	266	Jannaschia sp. CCS1	Mutation(s): 0 Gene Names: Jann_0659
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
SO4 Query on SO4 Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain F [auth B] SDF format, chain G [auth C] SDF format, chain H [auth C] SDF format, chain I [auth C] SDF format, chain J [auth C] SDF format, chain K [auth C] SDF format, chain L [auth D] SDF format, chain M [auth D] SDF format, chain N [auth D] MOL2 format, chain E [auth A] MOL2 format, chain F [auth B] MOL2 format, chain G [auth C] MOL2 format, chain H [auth C] MOL2 format, chain I [auth C] MOL2 format, chain J [auth C] MOL2 format, chain K [auth C] MOL2 format, chain L [auth D] MOL2 format, chain M [auth D] MOL2 format, chain N [auth D] mmCIF format, chain E [auth A] mmCIF format, chain F [auth B] mmCIF format, chain G [auth C] mmCIF format, chain H [auth C] mmCIF format, chain I [auth C] mmCIF format, chain J [auth C] mmCIF format, chain K [auth C] mmCIF format, chain L [auth D] mmCIF format, chain M [auth D] mmCIF format, chain N [auth D]	E [auth A] F [auth B] G [auth C] H [auth C] I [auth C] E [auth A], F [auth B], G [auth C], H [auth C], I [auth C], J [auth C], K [auth C], L [auth D], M [auth D], N [auth D]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain E [auth A] Focus chain F [auth B] Focus chain G [auth C] Focus chain H [auth C] Focus chain I [auth C] Focus chain J [auth C] Focus chain K [auth C] Focus chain L [auth D] Focus chain M [auth D] Focus chain N [auth D] Interactions & Density Focus chain E [auth A] Focus chain F [auth B] Focus chain G [auth C] Focus chain H [auth C] Focus chain I [auth C] Focus chain J [auth C] Focus chain K [auth C] Focus chain L [auth D] Focus chain M [auth D] Focus chain N [auth D]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B, C, D	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.81 Å
R-Value Free: 0.245 (Depositor), 0.260 (DCC)
R-Value Work: 0.199 (Depositor), 0.210 (DCC)
R-Value Observed: 0.202 (Depositor)

Diffraction Data: https://doi.org/10.18430/M33L09

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 69.953	α = 90
b = 81.722	β = 90
c = 199.921	γ = 90

Software Package:

Software Name	Purpose
BUSTER	refinement
PHENIX	refinement
SHELX	phasing
XSCALE	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
SHELXD	phasing
autoSHARP	phasing
MolProbity	model building

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2010-01-12

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2010-01-12
Type: Initial release
Version 1.1: 2011-07-13
Changes: Source and taxonomy, Version format compliance
Version 1.2: 2017-10-25
Changes: Author supporting evidence, Refinement description
Version 1.3: 2019-07-17
Changes: Data collection, Derived calculations, Refinement description
Version 1.4: 2023-02-01
Changes: Database references, Derived calculations
Version 1.5: 2024-11-27
Changes: Data collection, Structure summary
