3KYG

Crystal structure of VCA0042 (L135R) complexed with c-di-GMP


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.1 Å
  • R-Value Free: 0.240
  • R-Value Work: 0.201

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Structure of PP4397 Reveals the Molecular Basis for Different c-di-GMP Binding Modes by Pilz Domain Proteins.

Ko, J.Ryu, K.S.Kim, H.Shin, J.S.Lee, J.O.Cheong, C.Choi, B.S.

(2010) J.Mol.Biol. 398: 97-110

  • DOI: 10.1016/j.jmb.2010.03.007
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Cyclic diguanylate (c-di-GMP) is a global regulator that modulates pathogen virulence and biofilm formation in bacteria. Although a bioinformatic study revealed that PilZ domain proteins are the long-sought c-di-GMP binding proteins, the mechanism by ...

    Cyclic diguanylate (c-di-GMP) is a global regulator that modulates pathogen virulence and biofilm formation in bacteria. Although a bioinformatic study revealed that PilZ domain proteins are the long-sought c-di-GMP binding proteins, the mechanism by which c-di-GMP regulates them is uncertain. Pseudomonas putida PP4397 is one such protein that contains YcgR-N and PilZ domains and the apo-PP4397 structure was solved earlier by the Joint Center for Structural Genomics. We determined the crystal structure of holo-PP4397 and found that two intercalated c-di-GMPs fit into the junction of its YcgR-N and PilZ domains. Moreover, c-di-GMP binding induces PP4397 to undergo a dimer-to-monomer transition. Interestingly, another PilZ domain protein, VCA0042, binds to a single molecule of c-di-GMP, and both its apo and holo forms are dimeric. Mutational studies and the additional crystal structure of holo-VCA0042 (L135R) showed that the Arg122 residue of PP4397 is crucial for the recognition of two molecules of c-di-GMP. Thus, PilZ domain proteins exhibit different c-di-GMP binding stoichiometry and quaternary structure, and these differences are expected to play a role in generating diverse forms of c-di-GMP-mediated regulation.


    Organizational Affiliation

    Department of Chemistry, KAIST, Gusong-dong 373-1, Yuseong-gu, Daejeon 305-701, South Korea.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Putative uncharacterized protein VCA0042
A, B
227Vibrio cholerae serotype O1 (strain ATCC 39315 / El Tor Inaba N16961)Mutation(s): 1
Find proteins for Q9KNC3 (Vibrio cholerae serotype O1 (strain ATCC 39315 / El Tor Inaba N16961))
Go to UniProtKB:  Q9KNC3
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
5GP
Query on 5GP

Download SDF File
Download CCD File
A, B
GUANOSINE-5'-MONOPHOSPHATE
C10 H14 N5 O8 P
RQFCJASXJCIDSX-UUOKFMHZSA-N
 Ligand Interaction
External Ligand Annotations
IDBinding Affinity (Sequence Identity %)
5GPKd: 34.3 nM PDBBIND
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.1 Å
  • R-Value Free: 0.240
  • R-Value Work: 0.201
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 63.166α = 90.00
b = 67.233β = 90.00
c = 128.604γ = 90.00
Software Package:
Software NamePurpose
CNSrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2010-04-14
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Version format compliance
