3KTN

Crystal Structure of a putative 2-Keto-3-deoxygluconate Kinase from Enterococcus faecalis

• PDB DOI: https://doi.org/10.2210/pdb3KTN/pdb

• Classification: TRANSFERASE
• Organism(s): Enterococcus faecalis
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2009-11-25 Released: 2009-12-15
• Deposition Author(s): Satyanarayana, L., Burley, S.K., Swaminathan, S., New York SGX Research Center for Structural Genomics (NYSGXRC)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.26 Å
• R-Value Free: 0.238
• R-Value Work: 0.223
• R-Value Observed: 0.223

Literature

Crystal Structure of a putative 2-Keto-3-deoxygluconate Kinase from Enterococcus faecalis

Satyanarayana, L., Burley, S.K., Swaminathan, S.

To be published.

Biological Assembly 1

Global Symmetry: Dihedral - D3  (Explore in 3D)
Global Stoichiometry: Homo 6-mer - A6

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 39.8 kDa
• Atom Count: 2,881
• Modelled Residue Count: 340
• Deposited Residue Count: 346
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Carbohydrate kinase, pfkB family	A	346	Enterococcus faecalis	Mutation(s): 0  Gene Names: 1199733, EF_0840 EC: 2.7.1.45
UniProt
Find proteins for Q837J7 (Enterococcus faecalis (strain ATCC 700802 / V583)) Explore Q837J7  Go to UniProtKB:  Q837J7

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
SO4	B [auth A]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L
MG	C [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.26 Å
• R-Value Free: 0.238
• R-Value Work: 0.223
• R-Value Observed: 0.223
• Space Group: P 6₃ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 145.564	α = 90
b = 145.564	β = 90
c = 126.401	γ = 120

Software Package:

Software Name	Purpose
CBASS	data collection
SHELXCD	phasing
SHARP	phasing
CNS	refinement
DENZO	data reduction
HKL-2000	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2009-12-15
Deposition Author(s): Satyanarayana, L., Burley, S.K., Swaminathan, S., New York SGX Research Center for Structural Genomics (NYSGXRC)

Revision History

• Version 1.0: 2009-12-15
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Version format compliance
• Version 1.2: 2021-02-10
  Changes: Database references, Derived calculations, Structure summary
