3KRY

Crystal structure of MMP-13 in complex with SC-78080


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free: 0.256
  • R-Value Work: 0.206
  • R-Value Observed: 0.209

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.4 of the entry. See complete history


Literature

Orally-active MMP-1 sparing alpha-tetrahydropyranyl and alpha-piperidinyl sulfone matrix metalloproteinase (MMP) inhibitors with efficacy in cancer, arthritis, and cardiovascular disease

Becker, D.P.Barta, T.E.Bedell, L.J.Boehm, T.L.Bond, B.R.Carroll, J.Carron, C.P.Decrescenzo, G.A.Easton, A.M.Freskos, J.N.Funckes-Shippy, C.L.Heron, M.Hockerman, S.Howard, C.P.Kiefer, J.R.Li, M.H.Mathis, K.J.McDonald, J.J.Mehta, P.P.Munie, G.E.Sunyer, T.Swearingen, C.A.Villamil, C.I.Welsch, D.Williams, J.M.Yu, Y.Yao, J.

(2010) J Med Chem 53: 6653-6680

  • DOI: https://doi.org/10.1021/jm100669j
  • Primary Citation of Related Structures:
    3KRY

  • PubMed Abstract:

    α-Sulfone-α-piperidine and α-tetrahydropyranyl hydroxamates were explored that are potent inhibitors of MMP's-2, -9, and -13 that spare MMP-1, with oral efficacy in inhibiting tumor growth in mice and left-ventricular hypertrophy in rats and in the bovine cartilage degradation ex vivo explant system. α-Piperidine 19v (SC-78080/SD-2590) was selected for development toward the initial indication of cancer, while α-piperidine and α-tetrahydropyranyl hydroxamates 19w (SC-77964) and 9i (SC-77774), respectively, were identified as backup compounds.


  • Organizational Affiliation

    Pfizer Research, 700 Chesterfield Village Parkway, St. Louis, Missouri 63198, USA. dbecke3@luc.edu


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Collagenase 3
A, B, C, D
164Homo sapiensMutation(s): 0
Gene Names: MMP13
EC: 3.4.24
UniProt & NIH Common Fund Data Resources
Find proteins for P45452 (Homo sapiens)
Explore P45452
Go to UniProtKB:  P45452
PHAROS:  P45452
GTEx:  ENSG00000137745
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP45452
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
3KR
Query on 3KR

Download Ideal Coordinates CCD File
I [auth A],
N [auth B],
S [auth C],
X [auth D]
1-(2-methoxyethyl)-N-oxo-4-({4-[4-(trifluoromethoxy)phenoxy]phenyl}sulfonyl)piperidine-4-carboxamide
C22 H23 F3 N2 O7 S
JMZMOQBVAXNXIQ-UHFFFAOYSA-N
ZN
Query on ZN

Download Ideal Coordinates CCD File
E [auth A]
F [auth A]
J [auth B]
K [auth B]
O [auth C]
E [auth A],
F [auth A],
J [auth B],
K [auth B],
O [auth C],
P [auth C],
T [auth D],
U [auth D]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
CA
Query on CA

Download Ideal Coordinates CCD File
G [auth A]
H [auth A]
L [auth B]
M [auth B]
Q [auth C]
G [auth A],
H [auth A],
L [auth B],
M [auth B],
Q [auth C],
R [auth C],
V [auth D],
W [auth D]
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
Binding Affinity Annotations
IDSourceBinding Affinity
3KR PDBBind:  3KRY IC50: 0.1 (nM) from 1 assay(s)
Binding MOAD:  3KRY IC50: 0.1 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free: 0.256
  • R-Value Work: 0.206
  • R-Value Observed: 0.209
  • Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 36.317α = 92.42
b = 70.016β = 94.23
c = 69.094γ = 104.94
Software Package:
Software NamePurpose
MAR345data collection
X-PLORmodel building
REFMACrefinement
DENZOdata reduction
SCALEPACKdata scaling
X-PLORphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2010-10-06
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2015-06-24
    Changes: Data collection
  • Version 1.3: 2017-11-01
    Changes: Refinement description
  • Version 1.4: 2024-02-21
    Changes: Data collection, Database references, Derived calculations
