Beta Turn Optimization of the Gene-3-Protein of Filamentous Phage Fd

Experimental Data Snapshot

  • Resolution: 2.13 Å
  • R-Value Free: 0.271
  • R-Value Work: 0.214

wwPDB Validation   3D Report Full Report

This is version 1.4 of the entry. See complete history


Elimination of a cis-proline-containing loop and turn optimization stabilizes a protein and accelerates its folding.

Jakob, R.P.Zierer, B.K.Weininger, U.Hofmann, S.D.Lorenz, S.H.Balbach, J.Dobbek, H.Schmid, F.X.

(2010) J Mol Biol 399: 331-346

  • DOI: https://doi.org/10.1016/j.jmb.2010.04.007
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    In the N2 domain of the gene-3-protein of phage fd, two consecutive beta-strands are connected by a mobile loop of seven residues (157-163). The stability of this loop is low, and the Asp160-Pro161 bond at its tip shows conformational heterogeneity with 90% being in the cis and 10% in the trans form. The refolding kinetics of N2 are complex because the molecules with cis or trans isomers at Pro161 both fold to native-like conformations, albeit with different rates. We employed consensus design to shorten the seven-residue irregular loop around Pro161 to a four-residue type I' turn without a proline. This increased the conformational stability of N2 by almost 10 kJ mol(-1) and abolished the complexity of the folding kinetics. Turn sequences obtained from in vitro selections for increased stability strongly resembled those derived from the consensus design. Two other type I' turns of N2 could also be stabilized by consensus design. For all three turns, the gain in stability originates from an increase in the rate of refolding. The turns form native-like structures early during refolding and thus stabilize the folding transition state. The crystal structure of the variant with all three stabilized turns confirms that the 157-163 loop was in fact shortened to a type I' turn and that the other turns maintained their type I' conformation after sequence optimization.

  • Organizational Affiliation

    Laboratorium für Biochemie and Bayreuther Zentrum für Molekulare Biowissenschaften, Universität Bayreuth, D-95440 Bayreuth, Germany.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Attachment protein G3P
A, B
223Enterobacteria phage fdMutation(s): 24
Gene Names: 3III
Find proteins for P03661 (Enterobacteria phage fd)
Explore P03661
Go to UniProtKB:  P03661
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP03661
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 2.13 Å
  • R-Value Free: 0.271
  • R-Value Work: 0.214
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 56.513α = 90
b = 86.974β = 90
c = 96.29γ = 90
Software Package:
Software NamePurpose
MAR345dtbdata collection
XDSdata reduction
XDSdata scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2009-11-24
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2018-01-24
    Changes: Structure summary
  • Version 1.3: 2021-10-13
    Changes: Database references
  • Version 1.4: 2023-09-06
    Changes: Data collection, Refinement description
