3KMB

COMPLEX OF 3'-SULFO-LEWIS-X WITH A SELECTIN-LIKE MUTANT OF MANNOSE-BINDING PROTEIN A


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.95 Å
  • R-Value Free: 0.254
  • R-Value Work: 0.204
  • R-Value Observed: 0.204

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 2.0 of the entry. See complete history


Literature

Structure of a selectin-like mutant of mannose-binding protein complexed with sialylated and sulfated Lewis(x) oligosaccharides.

Ng, K.K.Weis, W.I.

(1997) Biochemistry 36: 979-988

  • DOI: 10.1021/bi962564e
  • Primary Citation of Related Structures:
    2KMB, 4KMB, 3KMB, 1KMB

  • PubMed Abstract:
  • Rat serum mannose-binding protein in which residues 211-213 have been changed to the Lys-Lys-Lys sequence found in E-selectin binds HL-60 cells and the oligosaccharide 3'-NeuAc-Le(x). To understand how this mutant, designated K3, mimics the carbohydrate-binding properties of E-selectin, structures of K3 alone and in complexes with 3'-NeuAc-Le(x), 3'-sulfo-Le(x) and 4'-sulfo-Le(x) have been determined at 1 ...

    Rat serum mannose-binding protein in which residues 211-213 have been changed to the Lys-Lys-Lys sequence found in E-selectin binds HL-60 cells and the oligosaccharide 3'-NeuAc-Le(x). To understand how this mutant, designated K3, mimics the carbohydrate-binding properties of E-selectin, structures of K3 alone and in complexes with 3'-NeuAc-Le(x), 3'-sulfo-Le(x) and 4'-sulfo-Le(x) have been determined at 1.95-2.1 A resolution by X-ray crystallography. The region of K3 that interacts with bound oligosaccharides superimposes closely with the corresponding region of unliganded E-selectin. In each of the oligosaccharide-protein complexes, the 2- and 3-OH of Fuc coordinate Ca2+ and form a network of cooperative hydrogen bonds with amino acid side chains that also coordinate the Ca2+. Lys211 of the K3 mutant, which corresponds to Lys111 of E-selectin, interacts with each of the three bound ligands: the N zeta atom donates a hydrogen bond to the 4-OH of Gal in 3'-NeuAc-Le(x), forms a water-mediated hydrogen bond with the 4-OH of Gal in 3'-sulfo-Le(x), and forms a salt bridge with the sulfate group of 4'-sulfo-Le(x). Lys213 packs against an otherwise exposed aromatic residue and forms a water-mediated hydrogen bond with Lys211 which may help to position that residue for interactions with bound oligosaccharides. These structures are consistent with previous mutagenesis and chemical modification studies which demonstrate the importance of the Ca2+ ligands as well as Lys111 and Lys113 for carbohydrate binding in the selectins, and they provide a structural basis for understanding the selective recognition of negatively charged Le(x) derivatives by the selectins.


    Related Citations:
    • Introduction of Selectin-Like Binding Specificity Into a Homologous Mannose-Binding Protein
      Blanck, O., Iobst, S.T., Gabel, C., Drickamer, K.
      (1996) J Biol Chem 271: 7289
    • Trimeric Structure of a C-Type Mannose-Binding Protein
      Weis, W.I., Drickamer, K.
      (1994) Structure 2: 1227

    Organizational Affiliation

    Department of Structural Biology, Stanford University School of Medicine, California 94305, USA.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
MANNOSE-BINDING PROTEIN-AA [auth 1], B [auth 2], C [auth 3]149Rattus norvegicusMutation(s): 3
Gene Names: Mbl1
UniProt
Find proteins for P19999 (Rattus norvegicus)
Explore P19999
Go to UniProtKB:  P19999
Protein Feature View
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 2
MoleculeChainsChain Length2D DiagramGlycosylation3D Interactions
alpha-L-fucopyranose-(1-3)-[3-O-sulfo-beta-D-galactopyranose-(1-4)]methyl 2-acetamido-2-deoxy-beta-D-glucopyranosideD [auth A]3N/A Oligosaccharides Interaction
Glycosylation Resources
GlyTouCan:  G53137CJ
GlyCosmos:  G53137CJ
Entity ID: 3
MoleculeChainsChain Length2D DiagramGlycosylation3D Interactions
alpha-L-fucopyranose-(1-3)-[3-O-sulfo-beta-D-galactopyranose-(1-4)]2-acetamido-2-deoxy-beta-D-glucopyranoseE [auth B]3N/A Oligosaccharides Interaction
Glycosylation Resources
GlyTouCan:  G12295TB
GlyCosmos:  G12295TB
GlyGen:  G12295TB
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
FUC (Subject of Investigation/LOI)
Query on FUC

Download Ideal Coordinates CCD File
K [auth 2]alpha-L-fucopyranose
C6 H12 O5
SHZGCJCMOBCMKK-SXUWKVJYSA-N
 Ligand Interaction
CA
Query on CA

Download Ideal Coordinates CCD File
F [auth 1] , G [auth 1] , H [auth 1] , I [auth 1] , L [auth 2] , M [auth 2] , N [auth 2] , P [auth 3] ,
F [auth 1],  G [auth 1],  H [auth 1],  I [auth 1],  L [auth 2],  M [auth 2],  N [auth 2],  P [auth 3],  Q [auth 3],  R [auth 3]
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
 Ligand Interaction
CL
Query on CL

Download Ideal Coordinates CCD File
J [auth 1], O [auth 2], S [auth 3]CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.95 Å
  • R-Value Free: 0.254
  • R-Value Work: 0.204
  • R-Value Observed: 0.204
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 79.1α = 90
b = 84.9β = 106.6
c = 97.2γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
X-PLORmodel building
X-PLORrefinement
X-PLORphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 1997-02-12
    Type: Initial release
  • Version 1.1: 2008-03-25
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Non-polymer description, Version format compliance
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Advisory, Atomic model, Data collection, Derived calculations, Structure summary
