3KJP | pdb_00003kjp

Crystal Structure of hPOT1V2-GGTTAGGGTTAG


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free:
    0.234 (Depositor), 0.235 (DCC)
  • R-Value Work:
    0.211 (Depositor), 0.211 (DCC)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 3KJP

This is version 1.2 of the entry. See complete history

Literature

How telomeric protein POT1 avoids RNA to achieve specificity for single-stranded DNA.

Nandakumar, J.Podell, E.R.Cech, T.R.

(2010) Proc Natl Acad Sci U S A 107: 651-656

  • DOI: https://doi.org/10.1073/pnas.0911099107
  • Primary Citation Related Structures:
    3KJO, 3KJP

  • PubMed Abstract:

    The POT1-TPP1 heterodimer, the major telomere-specific single-stranded DNA-binding protein in mammalian cells, protects chromosome ends and contributes to the regulation of telomerase. The recent discovery of telomeric RNA raises the question of how POT1 faithfully binds telomeric ssDNA and avoids illicit RNA binding that could result in its depletion from telomeres. Here we show through binding studies that a single deoxythymidine in a telomeric repeat dictates the DNA versus RNA discrimination by human POT1 and mouse POT1A. We solve the crystal structure of hPOT1 bound to DNA with a ribouridine in lieu of the critical deoxythymidine and show that this substitution results in burying the 2(')-hydroxyl group in a hydrophobic region (Phe62) of POT1 in addition to eliminating favorable hydrogen-bonding interactions at the POT1-nucleic acid interface. At amino acid 62, Phe discriminates against RNA binding and Tyr allows RNA binding. We further show that TPP1 greatly augments POT1's discrimination against RNA.


  • Organizational Affiliation
    • Department of Chemistry and Biochemistry, Howard Hughes Medical Institute, University of Colorado, Boulder, CO 80309-0215, USA.

Macromolecule Content

  • Total Structure Weight: 37.5 kDa
  • Atom Count: 2,777
  • Modeled Residue Count: 304
  • Deposited Residue Count: 311
  • Unique protein chains: 1
  • Unique nucleic acid chains: 1

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Protection of telomeres protein 1299Homo sapiensMutation(s): 0
Gene Names: POT1
UniProt & NIH Common Fund Data Resources
Find proteins for Q9NUX5 (Homo sapiens)
Explore Q9NUX5
Go to UniProtKB:  Q9NUX5
PHAROS:  Q9NUX5
GTEx:  ENSG00000128513
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9NUX5
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 2
MoleculeChains LengthOrganismImage
5'-D(*G*GP*TP*TP*AP*GP*GP*GP*TP*TP*AP*G)-3'12N/A
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free:  0.234 (Depositor), 0.235 (DCC)
  • R-Value Work:  0.211 (Depositor), 0.211 (DCC)
Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 102.112α = 90
b = 104.198β = 90
c = 71.607γ = 90
Software Package:
Software NamePurpose
MOLREPphasing
CNSrefinement
PDB_EXTRACTdata extraction
BOSdata collection
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2010-01-19
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2023-09-06
    Changes: Data collection, Database references, Refinement description
