3KJN

Caspase 8 bound to a covalent inhibitor


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free: 0.202
  • R-Value Work: 0.167
  • R-Value Observed: 0.170

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Kinetic and structural characterization of caspase-3 and caspase-8 inhibition by a novel class of irreversible inhibitors.

Wang, Z.Watt, W.Brooks, N.A.Harris, M.S.Urban, J.Boatman, D.McMillan, M.Kahn, M.Heinrikson, R.L.Finzel, B.C.Wittwer, A.J.Blinn, J.Kamtekar, S.Tomasselli, A.G.

(2010) Biochim Biophys Acta 1804: 1817-1831

  • DOI: 10.1016/j.bbapap.2010.05.007
  • Primary Citation of Related Structures:
    3KJN, 3KJQ, 3KJF

  • PubMed Abstract:
  • Because of their central role in programmed cell death, the caspases are attractive targets for developing new therapeutics against cancer and autoimmunity, myocardial infarction and ischemic damage, and neurodegenerative diseases. We chose to target caspase-3, an executioner caspase, and caspase-8, an initiator caspase, based on the vast amount of information linking their functions to diseases ...

    Because of their central role in programmed cell death, the caspases are attractive targets for developing new therapeutics against cancer and autoimmunity, myocardial infarction and ischemic damage, and neurodegenerative diseases. We chose to target caspase-3, an executioner caspase, and caspase-8, an initiator caspase, based on the vast amount of information linking their functions to diseases. Through a structure-based drug design approach, a number of novel beta-strand peptidomimetic compounds were synthesized. Kinetic studies of caspase-3 and caspase-8 inhibition were carried out with these urazole ring-containing irreversible peptidomimetics and a known irreversible caspase inhibitor, Z-VAD-fmk. Using a stopped-flow fluorescence assay, we were able to determine individual kinetic parameters of caspase-3 and caspase-8 inhibition by these inhibitors. Z-VAD-fmk and the peptidomimetic inhibitors inhibit caspase-3 and caspase-8 via a three-step kinetic mechanism. Inhibition of both caspase-3 and caspase-8 by Z-VAD-fmk and of caspase-3 by the peptidomimetic inhibitors proceeds via two rapid equilibrium steps followed by a relatively fast inactivation step. However, caspase-8 inhibition by the peptidomimetics goes through a rapid equilibrium step, a slow-binding reversible step, and an extremely slow inactivation step. The crystal structures of inhibitor complexes of caspases-3 and -8 validate the design of the inhibitors by illustrating in detail how they mimic peptide substrates. One of the caspase-8 structures also shows binding at a secondary, allosteric site, providing a possible route to the development of noncovalent small molecule modulators of caspase activity.


    Organizational Affiliation

    Oligonucleotide Therapeutics Unit, Pfizer, Inc., 620 Memorial Drive, Cambridge, MA 02139, USA. zhigang.wang@pfizer.com



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Caspase-8A164Homo sapiensMutation(s): 0
Gene Names: CASP8MCH5
EC: 3.4.22.61
UniProt & NIH Common Fund Data Resources
Find proteins for Q14790 (Homo sapiens)
Explore Q14790
Go to UniProtKB:  Q14790
PHAROS:  Q14790
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
Caspase-8B95Homo sapiensMutation(s): 0
Gene Names: CASP8MCH5
EC: 3.4.22.61
UniProt & NIH Common Fund Data Resources
Find proteins for Q14790 (Homo sapiens)
Explore Q14790
Go to UniProtKB:  Q14790
PHAROS:  Q14790
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
B93
Query on B93

Download Ideal Coordinates CCD File
D [auth A](3S)-3-({[(5S)-2-{2-[(1H-benzimidazol-5-ylcarbonyl)amino]ethyl}-7-(cyclohexylmethyl)-1,3-dioxo-2,3,5,8-tetrahydro-1H-[1,2,4]triazolo[1,2-a]pyridazin-5-yl]carbonyl}amino)-4-oxopentanoic acid
C29 H35 N7 O7
CSBIJWXSABAIKK-UPVQGACJSA-N
 Ligand Interaction
DTT
Query on DTT

Download Ideal Coordinates CCD File
C [auth A]2,3-DIHYDROXY-1,4-DITHIOBUTANE
C4 H10 O2 S2
VHJLVAABSRFDPM-IMJSIDKUSA-N
 Ligand Interaction
External Ligand Annotations
IDBinding Affinity (Sequence Identity %)
B93Ki :  6440   nM  PDBBind
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free: 0.202
  • R-Value Work: 0.167
  • R-Value Observed: 0.170
  • Space Group: P 31 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 62.598α = 90
b = 62.598β = 90
c = 129.389γ = 120
Software Package:
Software NamePurpose
HKL-2000data collection
AMoREphasing
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2010-08-11
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
