3K4U | pdb_00003k4u

CRYSTAL STRUCTURE OF putative binding component of ABC transporter from Wolinella succinogenes DSM 1740 complexed with lysine

• PDB DOI: https://doi.org/10.2210/pdb3K4U/pdb

• Classification: TRANSPORT PROTEIN
• Organism(s): Wolinella succinogenes
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2009-10-06 Released: 2009-11-03
• Deposition Author(s): Malashkevich, V.N., Toro, R., Morano, C., Sauder, J.M., Burley, S.K., Almo, S.C., New York SGX Research Center for Structural Genomics (NYSGXRC)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.62 Å
• R-Value Free:
  0.266 (Depositor), 0.260 (DCC)
• R-Value Work:
  0.202 (Depositor), 0.197 (DCC)
• R-Value Observed:
  0.205 (Depositor)

Literature

CRYSTAL STRUCTURE OF putative binding component of ABC transporter from Wolinella succinogenes DSM 1740 complexed with lysine

Malashkevich, V.N., Toro, R., Morano, C., Sauder, J.M., Burley, S.K., Almo, S.C.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Homo 5-mer - A5 Local Symmetry: Cyclic - C3  (Explore in 3D)
Local Stoichiometry: Homo 3-mer - A3

Local Symmetry: Cyclic - C3  (Explore in 3D)
Local Stoichiometry: Homo 3-mer - A3

Biological assembly 1 generated by PISA (software)

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Homo 6-mer - A6

Local Symmetry: Cyclic - C3  (Explore in 3D)
Local Stoichiometry: Homo 3-mer - A3 Local Symmetry: Cyclic - C3  (Explore in 3D)
Local Stoichiometry: Homo 3-mer - A3

Biological assembly 2 generated by PISA (software)

Biological Assembly 3

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Homo 6-mer - A6

Local Symmetry: Cyclic - C3  (Explore in 3D)
Local Stoichiometry: Homo 3-mer - A3 Local Symmetry: Cyclic - C3  (Explore in 3D)
Local Stoichiometry: Homo 3-mer - A3

Biological assembly 3 assigned by authors.

Macromolecule Content

• Total Structure Weight: 170.93 kDa
• Atom Count: 11,414
• Modeled Residue Count: 1,399
• Deposited Residue Count: 1,470
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
BINDING COMPONENT OF ABC TRANSPORTER	A, B, C, D, E, F	245	Wolinella succinogenes	Mutation(s): 0  Gene Names: CAE09431.1, WS0279
UniProt
Find proteins for Q7MAG0 (Wolinella succinogenes (strain ATCC 29543 / DSM 1740 / CCUG 13145 / JCM 31913 / LMG 7466 / NCTC 11488 / FDC 602W)) Explore Q7MAG0  Go to UniProtKB:  Q7MAG0

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
LYS	G [auth A], H [auth B], I [auth C], J [auth D], K [auth E], L [auth F]	LYSINE C6 H15 N2 O2 KDXKERNSBIXSRK-YFKPBYRVSA-O

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B, C, D, E, F	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.62 Å
• R-Value Free:  0.266 (Depositor), 0.260 (DCC)
• R-Value Work:  0.202 (Depositor), 0.197 (DCC)
• R-Value Observed: 0.205 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 79.406	α = 90
b = 149.151	β = 100.46
c = 81.969	γ = 90

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
SHELX	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction
HKL-2000	data reduction
SHELXD	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2009-11-03
Deposition Author(s): Malashkevich, V.N., Toro, R., Morano, C., Sauder, J.M., Burley, S.K., Almo, S.C., New York SGX Research Center for Structural Genomics (NYSGXRC)

Revision History

• Version 1.0: 2009-11-03
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Advisory, Refinement description, Version format compliance
• Version 1.2: 2012-10-24
  Changes: Structure summary
• Version 1.3: 2017-11-01
  Changes: Refinement description
• Version 1.4: 2018-11-21
  Changes: Data collection, Structure summary
• Version 1.5: 2021-02-10
  Changes: Database references, Derived calculations, Structure summary
• Version 1.6: 2024-10-09
  Changes: Data collection, Database references, Structure summary
