3K1F

Crystal structure of RNA Polymerase II in complex with TFIIB


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 4.3 Å
  • R-Value Free: 0.255
  • R-Value Work: 0.220

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

RNA polymerase II-TFIIB structure and mechanism of transcription initiation.

Kostrewa, D.Zeller, M.E.Armache, K.J.Seizl, M.Leike, K.Thomm, M.Cramer, P.

(2009) Nature 462: 323-330

  • DOI: 10.1038/nature08548

  • PubMed Abstract:
  • To initiate gene transcription, RNA polymerase II (Pol II) requires the transcription factor IIB (B). Here we present the crystal structure of the complete Pol II-B complex at 4.3 A resolution, and complementary functional data. The results indicate ...

    To initiate gene transcription, RNA polymerase II (Pol II) requires the transcription factor IIB (B). Here we present the crystal structure of the complete Pol II-B complex at 4.3 A resolution, and complementary functional data. The results indicate the mechanism of transcription initiation, including the transition to RNA elongation. Promoter DNA is positioned over the Pol II active centre cleft with the 'B-core' domain that binds the wall at the end of the cleft. DNA is then opened with the help of the 'B-linker' that binds the Pol II rudder and clamp coiled-coil at the edge of the cleft. The DNA template strand slips into the cleft and is scanned for the transcription start site with the help of the 'B-reader' that approaches the active site. Synthesis of the RNA chain and rewinding of upstream DNA displace the B-reader and B-linker, respectively, to trigger B release and elongation complex formation.


    Organizational Affiliation

    Gene Center Munich and Center for Integrated Protein Science Munich (CIPSM), Department of Chemistry and Biochemistry, Ludwig-Maximilians-Universit√§t M√ľnchen, Feodor-Lynen-Strasse 25, 81377 Munich, Germany.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerase II subunit RPB1
A
1733Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: RPO21 (RPB1, RPB220, SUA8)
EC: 2.7.7.6
Find proteins for P04050 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P04050
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerase II subunit RPB2
B
1224Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: RPB2 (RPB150, RPO22)
EC: 2.7.7.6
Find proteins for P08518 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P08518
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerase II subunit RPB3
C
318Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: RPB3
Find proteins for P16370 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P16370
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerase II subunit RPB4
D
221Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: RPB4
Find proteins for P20433 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P20433
Entity ID: 5
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerases I, II, and III subunit RPABC1
E
215Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: RPB5 (RPA7, RPC9)
Find proteins for P20434 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P20434
Entity ID: 6
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerases I, II, and III subunit RPABC2
F
155Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: RPO26 (RPB6)
Find proteins for P20435 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P20435
Entity ID: 7
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerase II subunit RPB7
G
171Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: RPB7
Find proteins for P34087 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P34087
Entity ID: 8
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerases I, II, and III subunit RPABC3
H
146Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: RPB8
Find proteins for P20436 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P20436
Entity ID: 9
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerase II subunit RPB9
I
122Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: RPB9
Find proteins for P27999 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P27999
Entity ID: 10
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerases I, II, and III subunit RPABC5
J
70Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: RPB10
Find proteins for P22139 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P22139
Entity ID: 11
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerase II subunit RPB11
K
120Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: RPB11
Find proteins for P38902 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P38902
Entity ID: 12
MoleculeChainsSequence LengthOrganismDetails
DNA-directed RNA polymerases I, II, and III subunit RPABC4
L
70Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: RPC10 (RPB12)
Find proteins for P40422 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P40422
Entity ID: 13
MoleculeChainsSequence LengthOrganismDetails
Transcription initiation factor IIB
M
197Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Gene Names: SUA7
Find proteins for P29055 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P29055
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download SDF File
Download CCD File
A, B, C, I, J, L, M
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
UNK
Query on UNK
M
L-PEPTIDE LINKINGC4 H9 N O2

--

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 4.3 Å
  • R-Value Free: 0.255
  • R-Value Work: 0.220
  • Space Group: C 2 2 21
Unit Cell:
Length (Å)Angle (°)
a = 220.970α = 90.00
b = 408.270β = 90.00
c = 275.240γ = 90.00
Software Package:
Software NamePurpose
PHASERphasing
BUSTERrefinement
ADSCdata collection
XDSdata reduction
XSCALEdata scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2009-11-10
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Version format compliance
  • Version 1.2: 2013-05-01
    Type: Other
