3JR4

MutM interrogating an extrahelical G


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.601 Å
  • R-Value Free: 0.237
  • R-Value Work: 0.190

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Entrapment and structure of an extrahelical guanine attempting to enter the active site of a bacterial DNA glycosylase, MutM.

Qi, Y.Spong, M.C.Nam, K.Karplus, M.Verdine, G.L.

(2010) J.Biol.Chem. 285: 1468-1478

  • DOI: 10.1074/jbc.M109.069799
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • MutM, a bacterial DNA glycosylase, protects genome integrity by catalyzing glycosidic bond cleavage of 8-oxoguanine (oxoG) lesions, thereby initiating base excision DNA repair. The process of searching for and locating oxoG lesions is especially chal ...

    MutM, a bacterial DNA glycosylase, protects genome integrity by catalyzing glycosidic bond cleavage of 8-oxoguanine (oxoG) lesions, thereby initiating base excision DNA repair. The process of searching for and locating oxoG lesions is especially challenging, because of the close structural resemblance of oxoG to its million-fold more abundant progenitor, G. Extrusion of the target nucleobase from the DNA double helix to an extrahelical position is an essential step in lesion recognition and catalysis by MutM. Although the interactions between the extruded oxoG and the active site of MutM have been well characterized, little is known in structural detail regarding the interrogation of extruded normal DNA bases by MutM. Here we report the capture and structural elucidation of a complex in which MutM is attempting to present an undamaged G to its active site. The structure of this MutM-extrahelical G complex provides insights into the mechanism MutM employs to discriminate against extrahelical normal DNA bases and into the base extrusion process in general.


    Organizational Affiliation

    Graduate Program in Biophysics, Harvard Medical School, Boston, Massachusetts 02115, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure


Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
DNA glycosylase
A
273Geobacillus stearothermophilusMutation(s): 1
Gene Names: mutM (fpg)
EC: 3.2.2.23
Find proteins for P84131 (Geobacillus stearothermophilus)
Go to UniProtKB:  P84131
Entity ID: 2
MoleculeChainsLengthOrganism
DNA (5'-D(*AP*GP*GP*TP*AP*GP*AP*CP*CP*TP*GP*GP*AP*CP*GP*C)-3')B16N/A
Entity ID: 3
MoleculeChainsLengthOrganism
DNA (5'-D(*TP*G*CP*GP*TP*CP*CP*AP*(GX1)P*GP*TP*CP*TP*AP*CP*C)-3')C16N/A
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download SDF File
Download CCD File
A
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
GX1
Query on GX1
C
DNA linkingC12 H19 N6 O6 P SDG
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.601 Å
  • R-Value Free: 0.237
  • R-Value Work: 0.190
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 45.343α = 90.00
b = 95.377β = 90.00
c = 102.482γ = 90.00
Software Package:
Software NamePurpose
SCALEPACKdata scaling
ADSCdata collection
PDB_EXTRACTdata extraction
DENZOdata reduction
PHENIXrefinement
PHENIXphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2009-11-03
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Version format compliance
  • Version 1.2: 2017-11-01
    Type: Refinement description
