3IX4

LasR-TP1 complex


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.8 Å
  • R-Value Free: 0.247
  • R-Value Work: 0.199

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Molecular basis for the recognition of structurally distinct autoinducer mimics by the Pseudomonas aeruginosa LasR quorum-sensing signaling receptor.

Zou, Y.Nair, S.K.

(2009) Chem.Biol. 16: 961-970

  • DOI: 10.1016/j.chembiol.2009.09.001
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • The human pathogen Pseudomonas aeruginosa coordinates the expression of virulence factors using quorum sensing, a signaling cascade triggered by the activation of signal receptors by small-molecule autoinducers. These homoserine lactone autoinducers ...

    The human pathogen Pseudomonas aeruginosa coordinates the expression of virulence factors using quorum sensing, a signaling cascade triggered by the activation of signal receptors by small-molecule autoinducers. These homoserine lactone autoinducers stabilize their cognate receptors and activate their functions as transcription factors. Because quorum sensing regulates the progression of infection and host immune resistance, significant efforts have been devoted toward the identification of small molecules that disrupt this process. Screening efforts have identified a class of triphenyl compounds that are structurally distinct from the homoserine lactone autoinducer, yet interact specifically and potently with LasR receptor to modulate quorum sensing (Muh et al., 2006a). Here we present the high-resolution crystal structures of the ligand binding domain of LasR in complex with the autoinducer N-3-oxo-dodecanoyl homoserine lactone (1.4 A resolution), and with the triphenyl mimics TP-1, TP-3, and TP-4 (to between 1.8 A and 2.3 A resolution). These crystal structures provide a molecular rationale for understanding how chemically distinct compounds can be accommodated by a highly selective receptor, and provide the framework for the development of novel quorum-sensing regulators, utilizing the triphenyl scaffold.


    Organizational Affiliation

    Department of Biochemistry, University of Illinois at Urbana-Champaign, 600 S. Mathews Avenue, Urbana, IL 61801, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Transcriptional activator protein lasR
A, B, C, D, E, F, G, H
173Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1)Mutation(s): 0
Gene Names: lasR
Find proteins for P25084 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1))
Go to UniProtKB:  P25084
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
TX1
Query on TX1

Download SDF File
Download CCD File
A, B, C, D, E, F, G, H
2,4-dibromo-6-({[(2-nitrophenyl)carbonyl]amino}methyl)phenyl 2-chlorobenzoate
C21 H13 Br2 Cl N2 O5
WKUUVOPOQKZMFY-UHFFFAOYSA-N
 Ligand Interaction
External Ligand Annotations
IDBinding Affinity (Sequence Identity %)
TX1EC50: 28 nM (100) BINDINGDB
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.8 Å
  • R-Value Free: 0.247
  • R-Value Work: 0.199
  • Space Group: P 1 21 1
Unit Cell:
Length (Å)Angle (°)
a = 54.196α = 90.00
b = 84.546β = 95.97
c = 156.385γ = 90.00
Software Package:
Software NamePurpose
REFMACrefinement
PHASERphasing
HKL-2000data reduction
MAR345dtbdata collection
HKL-2000data scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

  • Deposited Date: 2009-09-03
  • Released Date: 2009-09-15
  • Deposition Author(s): Zou, Y., Nair, S.K.

Revision History

  • Version 1.0: 2009-09-15
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Version format compliance
