3ISV

Crystal structure of glutamate racemase from Listeria monocytogenes in complex with acetate ion


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.85 Å
  • R-Value Free: 0.224
  • R-Value Work: 0.172
  • R-Value Observed: 0.174

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.5 of the entry. See complete history


Literature

Crystal structure of glutamate racemase from Listeria monocytogenes in complex with acetate ion

Majorek, K.A.Chruszcz, M.Skarina, T.Onopriyenko, O.Stam, J.Anderson, W.F.Savchenko, A.Bujnicki, J.M.Minor, W.Center for Structural Genomics of Infectious Diseases (CSGID)

To be published.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Glutamate racemase
A, B
269Listeria monocytogenes EGD-eMutation(s): 0
Gene Names: lmo1237murIracE
EC: 5.1.1.3
UniProt
Find proteins for Q8Y7N7 (Listeria monocytogenes serovar 1/2a (strain ATCC BAA-679 / EGD-e))
Explore Q8Y7N7
Go to UniProtKB:  Q8Y7N7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8Y7N7
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A, B
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

Unit Cell:
Length ( Å )Angle ( ˚ )
a = 66.763α = 90
b = 66.763β = 90
c = 258.602γ = 90
Software Package:
Software NamePurpose
HKL-2000data collection
HKL-3000phasing
REFMACrefinement
Cootmodel building
HKL-3000data reduction
HKL-3000data scaling

Structure Validation

View Full Validation Report



Entry History

Revision History  (Full details and data files)

  • Version 1.0: 2009-09-22
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Advisory, Version format compliance
  • Version 1.2: 2022-04-13
    Changes: Database references, Derived calculations, Structure summary
  • Version 1.3: 2023-09-06
    Changes: Data collection, Refinement description
  • Version 1.4: 2023-11-22
    Changes: Data collection
  • Version 1.5: 2024-11-06
    Changes: Structure summary
