3IE7

The crystal structure of phosphofructokinase (lin2199) from Listeria innocua in complex with ATP at 1.6A

• PDB DOI:  https://doi.org/10.2210/pdb3IE7/pdb

• Classification: TRANSFERASE
• Organism(s): Listeria innocua
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2009-07-22 Released: 2009-08-04
• Deposition Author(s): Satyanarayana, L., Burley, S.K., Swaminathan, S., New York SGX Research Center for Structural Genomics (NYSGXRC)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.60 Å
• R-Value Free: 0.239
• R-Value Work: 0.219
• R-Value Observed: 0.219

Literature

The crystal structure of phosphofructokinase (lin2199) from Listeria innocua in complex with ATP at 1.6A

Satyanarayana, L., Burley, S.K., Swaminathan, S.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (3D View)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 36.01 kDa
• Atom Count: 2,664
• Modelled Residue Count: 309
• Deposited Residue Count: 320
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Lin2199 protein	A	320	Listeria innocua	Mutation(s): 0  Gene Names: lin2199 EC: 2.7.1 (PDB Primary Data), 2.7.1.144 (UniProt)
UniProt
Find proteins for Q929S5 (Listeria innocua serovar 6a (strain ATCC BAA-680 / CLIP 11262)) Explore Q929S5  Go to UniProtKB:  Q929S5

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ATP	B [auth A]	ADENOSINE-5'-TRIPHOSPHATE C10 H16 N5 O13 P3 ZKHQWZAMYRWXGA-KQYNXXCUSA-N
GOL	F [auth A]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N
MG	C [auth A], D [auth A], E [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.60 Å
• R-Value Free: 0.239
• R-Value Work: 0.219
• R-Value Observed: 0.219
• Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 146.108	α = 90
b = 46.244	β = 102.08
c = 57.762	γ = 90

Software Package:

Software Name	Purpose
CBASS	data collection
MOLREP	phasing
CNS	refinement
DENZO	data reduction
HKL-2000	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2009-08-04
Deposition Author(s): Satyanarayana, L., Burley, S.K., Swaminathan, S., New York SGX Research Center for Structural Genomics (NYSGXRC)

Revision History

• Version 1.0: 2009-08-04
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Non-polymer description, Version format compliance
• Version 1.2: 2021-02-10
  Changes: Database references, Derived calculations, Structure summary
• Version 1.3: 2023-09-06
  Changes: Data collection, Database references, Refinement description
