3HZ5 | pdb_00003hz5

Crystal structure of Hsp90 with fragment Z064

PDB DOI: https://doi.org/10.2210/pdb3HZ5/pdb

Classification: CHAPERONE
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2009-06-23 Released: 2010-07-14
Deposition Author(s): Barker, J., Mather, O., Cheng, R.K.Y., Palan, S., Felicetti, B., Whittaker, M.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free:
0.254 (Depositor), 0.240 (DCC)
R-Value Work:
0.214 (Depositor), 0.205 (DCC)
R-Value Observed:
0.216 (Depositor)

Starting Model: other
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 3HZ5

Ligand Structure Quality Assessment

This is version 1.3 of the entry. See complete history.

Literature

Crystal structure of Hsp90 with fragment Z064

Barker, J., Mather, O., Cheng, R.K.Y., Palan, S., Felicetti, B., Whittaker, M.

To be published.

Macromolecule Content

Total Structure Weight: 28.31 kDa
Atom Count: 1,880
Modeled Residue Count: 208
Deposited Residue Count: 249
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Heat shock protein HSP 90-alpha	A	249	Homo sapiens	Mutation(s): 0 EC: 3.6.4.10
UniProt & NIH Common Fund Data Resources
Find proteins for P07900 (Homo sapiens) Explore P07900 Go to UniProtKB: P07900
PHAROS: P07900 GTEx: ENSG00000080824
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P07900
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
Z64 Query on Z64 Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	N-[4-(5-furan-2-yl-3-methyl-1H-pyrazol-4-yl)butyl]-N-methyl-7H-purin-6-amine C₁₈ H₂₁ N₇ O PBUASXAIYKZEKU-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free: 0.254 (Depositor), 0.240 (DCC)
R-Value Work: 0.214 (Depositor), 0.205 (DCC)
R-Value Observed: 0.216 (Depositor)

Space Group: I 2 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 66.64	α = 90
b = 90.849	β = 90
c = 98.744	γ = 90

Software Package:

Software Name	Purpose
CrystalClear	data collection
MOLREP	phasing
REFMAC	refinement
CrystalClear	data reduction
CrystalClear	data scaling

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2010-07-14

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2010-07-14
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2024-03-20
Changes: Data collection, Database references, Derived calculations
Version 1.3: 2024-04-03
Changes: Refinement description
