3HR9 | pdb_00003hr9

The truncated Fibrobacter succinogenes 1,3-1,4-beta-D-glucanase F40I mutant

PDB DOI: https://doi.org/10.2210/pdb3HR9/pdb
Entry: 3HR9 supersedes: 2R4A

Classification: HYDROLASE
Organism(s): Fibrobacter succinogenes
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2009-06-09 Released: 2009-07-07
Deposition Author(s): Tsai, L.C., Huang, H.C., Hsiao, C.H.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free:
0.229 (Depositor), 0.228 (DCC)
R-Value Work:
0.193 (Depositor), 0.193 (DCC)
R-Value Observed:
0.193 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 3HR9

This is version 1.3 of the entry. See complete history.

Literature

The truncated Fibrobacter succinogenes 1,3-1,4-beta-D-glucanase mutant F40I

Tsai, L.C., Huang, H.C., Je-Hsin, C., Lie-Fen, S.

To be published.

Macromolecule Content

Total Structure Weight: 27.29 kDa
Atom Count: 2,163
Modeled Residue Count: 241
Deposited Residue Count: 241
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Beta-glucanase	A	241	Fibrobacter succinogenes	Mutation(s): 1 Gene Names: succinogenes EC: 3.2.1.73
UniProt
Find proteins for P17989 (Fibrobacter succinogenes (strain ATCC 19169 / S85)) Explore P17989 Go to UniProtKB: P17989
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P17989
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
TRS Query on TRS Download:Ideal Coordinates CCD File SDF format, chain E [auth A] MOL2 format, chain E [auth A] mmCIF format, chain E [auth A]	E [auth A]	2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL C₄ H₁₂ N O₃ LENZDBCJOHFCAS-UHFFFAOYSA-O		Interactions Focus chain E [auth A] Interactions & Density Focus chain E [auth A]
ACT Query on ACT Download:Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A]	F [auth A], G [auth A], H [auth A]	ACETATE ION C₂ H₃ O₂ QTBSBXVTEAMEQO-UHFFFAOYSA-M		Interactions Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Interactions & Density Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A]
CA Query on CA Download:Ideal Coordinates CCD File SDF format, chain B [auth A] SDF format, chain C [auth A] SDF format, chain D [auth A] MOL2 format, chain B [auth A] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] mmCIF format, chain B [auth A] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A]	B [auth A], C [auth A], D [auth A]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free: 0.229 (Depositor), 0.228 (DCC)
R-Value Work: 0.193 (Depositor), 0.193 (DCC)
R-Value Observed: 0.193 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 60.3	α = 90
b = 68.03	β = 90
c = 70.46	γ = 90

Software Package:

Software Name	Purpose
CrystalClear	data collection
CNS	refinement
DENZO	data reduction
SCALEPACK	data scaling
CNS	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2009-07-07

Deposition Author(s):

This entry supersedes: 2R4A

Revision History (Full details and data files)

Version 1.0: 2009-07-07
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2021-11-10
Changes: Database references, Derived calculations
Version 1.3: 2023-11-01
Changes: Data collection, Refinement description
