3HN2 | pdb_00003hn2

Crystal structure of 2-dehydropantoate 2-reductase FROM Geobacter metallireducens GS-15

PDB DOI: https://doi.org/10.2210/pdb3HN2/pdb

Classification: OXIDOREDUCTASE
Organism(s): Geobacter metallireducens GS-15
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2009-05-29 Released: 2009-06-09
Deposition Author(s): Patskovsky, Y., Toro, R., Morano, C., Rutter, M., Chang, S., Sauder, J.M., Burley, S.K., Almo, S.C., New York SGX Research Center for Structural Genomics (NYSGXRC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.50 Å
R-Value Free:
0.292 (Depositor), 0.292 (DCC)
R-Value Work:
0.243 (Depositor), 0.243 (DCC)
R-Value Observed:
0.244 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3HN2

This is version 1.5 of the entry. See complete history.

Literature

Crystal structure of 2-dehydropantoate 2-reductase FROM Geobacter metallireducens

Patskovsky, Y., Toro, R., Morano, C., Rutter, M., Chang, S., Sauder, J.M., Burley, S.K., Almo, S.C.

To be published.

Macromolecule Content

Total Structure Weight: 137.41 kDa
Atom Count: 9,315
Modeled Residue Count: 1,207
Deposited Residue Count: 1,248
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
2-dehydropantoate 2-reductase	A, B, C, D	312	Geobacter metallireducens GS-15	Mutation(s): 0 Gene Names: Gmet_2643 EC: 1.1.1.169
UniProt
Find proteins for Q39SB2 (Geobacter metallireducens (strain ATCC 53774 / DSM 7210 / GS-15)) Explore Q39SB2 Go to UniProtKB: Q39SB2
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q39SB2
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.50 Å
R-Value Free: 0.292 (Depositor), 0.292 (DCC)
R-Value Work: 0.243 (Depositor), 0.243 (DCC)
R-Value Observed: 0.244 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 77.318	α = 90
b = 82.179	β = 90
c = 201.291	γ = 90

Software Package:

Software Name	Purpose
RESOLVE	model building
REFMAC	refinement
DENZO	data reduction
HKL-2000	data scaling
SHELXDE	phasing
RESOLVE	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2009-06-09

Deposition Author(s):

New York SGX Research Center for Structural Genomics (NYSGXRC)

Revision History (Full details and data files)

Version 1.0: 2009-06-09
Type: Initial release
Version 1.1: 2011-07-13
Changes: Advisory, Refinement description, Source and taxonomy, Version format compliance
Version 1.2: 2018-11-21
Changes: Data collection, Structure summary
Version 1.3: 2018-11-28
Changes: Data collection, Refinement description
Version 1.4: 2021-02-10
Changes: Database references, Structure summary
Version 1.5: 2024-02-21
Changes: Data collection, Database references
