3HLN

Crystal structure of ClpP A153C mutant with inter-heptamer disulfide bonds


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.2 Å
  • R-Value Free: 0.253
  • R-Value Work: 0.213

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Structural and Theoretical Studies Indicate that the Cylindrical Protease ClpP Samples Extended and Compact Conformations.

Kimber, M.S.Yu, A.Y.Borg, M.Leung, E.Chan, H.S.Houry, W.A.

(2010) Structure 18: 798-808

  • DOI: 10.1016/j.str.2010.04.008

  • PubMed Abstract:
  • The highly conserved ClpP protease consists of two heptameric rings that interact by the interdigitation of an alpha-helix beta strand handle domain motif to form a tetradecameric cylinder. We previously proposed that protease dynamics results in the ...

    The highly conserved ClpP protease consists of two heptameric rings that interact by the interdigitation of an alpha-helix beta strand handle domain motif to form a tetradecameric cylinder. We previously proposed that protease dynamics results in the temporary unstructuring of interacting pairs of handle domains, opening transient equatorial side pores that allow for peptide egress. Here, we report the structure of an Escherichia coli ClpP mutant in which each opposing pair of protomers is linked by a disulfide bond. This structure resembles the compact structures of Streptococcus pneumoniae, Mycobacterium tuberculosis, and Plasmodium falciparum ClpPs, rather than the active, extended structures that have previously been determined for E. coli ClpPs. The structural data, along with normal mode analysis, support a model whereby the ClpP cylinder switches dynamically between an active extended state required for substrate degradation and an inactive compact state allowing peptide product release.


    Organizational Affiliation

    Department of Molecular and Cellular Biology, University of Guelph, Guelph, ON N1G 2W1, Canada.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
ATP-dependent Clp protease proteolytic subunit
A, B, C, D, E, F, G, H, I, J, K, L, M, N, O, P, Q, R, S, T, U, V, W, X, Y, Z, 1, 2
193Escherichia coli (strain K12)Mutation(s): 1
Gene Names: clpP (lopP)
EC: 3.4.21.92
Find proteins for P0A6G7 (Escherichia coli (strain K12))
Go to UniProtKB:  P0A6G7
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
CA
Query on CA

Download SDF File
Download CCD File
1, 2, E, I, J, M, T, V, Z
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.2 Å
  • R-Value Free: 0.253
  • R-Value Work: 0.213
  • Space Group: P 32 2 1
Unit Cell:
Length (Å)Angle (°)
a = 182.299α = 90.00
b = 182.299β = 90.00
c = 476.859γ = 120.00
Software Package:
Software NamePurpose
REFMACrefinement
ADSCdata collection
MOLREPphasing
HKL-3000data reduction
HKL-3000data scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2010-07-28
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Source and taxonomy, Version format compliance
