3H2Z | pdb_00003h2z

The crystal structure of mannitol-1-phosphate dehydrogenase from Shigella flexneri

PDB DOI: https://doi.org/10.2210/pdb3H2Z/pdb

Classification: OXIDOREDUCTASE
Organism(s): Shigella flexneri 2a str. 2457T
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2009-04-15 Released: 2009-06-16
Deposition Author(s): Wu, R., Clancy, S., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free:
0.204 (Depositor), 0.210 (DCC)
R-Value Work:
0.174 (Depositor), 0.179 (DCC)
R-Value Observed:
0.176 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

The crystal structure of mannitol-1-phosphate dehydrogenase from Shigella flexneri

Wu, R., Clancy, S., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 42.39 kDa
Atom Count: 3,236
Modeled Residue Count: 377
Deposited Residue Count: 382
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Mannitol-1-phosphate 5-dehydrogenase	A	382	Shigella flexneri 2a str. 2457T	Mutation(s): 0 Gene Names: mtlD, S4134, SF3634 EC: 1.1.1.17
UniProt
Find proteins for Q83PQ0 (Shigella flexneri) Explore Q83PQ0 Go to UniProtKB: Q83PQ0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q83PQ0
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
PO4 Query on PO4 Download Ideal Coordinates CCD File SDF format, chain L [auth A] SDF format, chain M [auth A] SDF format, chain O [auth A] SDF format, chain N [auth A] MOL2 format, chain L [auth A] MOL2 format, chain M [auth A] MOL2 format, chain O [auth A] MOL2 format, chain N [auth A] mmCIF format, chain L [auth A] mmCIF format, chain M [auth A] mmCIF format, chain O [auth A] mmCIF format, chain N [auth A]	L [auth A], M [auth A], N [auth A], O [auth A]	PHOSPHATE ION O₄ P NBIIXXVUZAFLBC-UHFFFAOYSA-K		Interactions Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Interactions & Density Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A]
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain E [auth A] MOL2 format, chain E [auth A] mmCIF format, chain E [auth A]	E [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Interactions & Density Focus chain E [auth A]
ACT Query on ACT Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain G [auth A] SDF format, chain D [auth A] SDF format, chain B [auth A] MOL2 format, chain C [auth A] MOL2 format, chain G [auth A] MOL2 format, chain D [auth A] MOL2 format, chain B [auth A] mmCIF format, chain C [auth A] mmCIF format, chain G [auth A] mmCIF format, chain D [auth A] mmCIF format, chain B [auth A]	B [auth A], C [auth A], D [auth A], G [auth A]	ACETATE ION C₂ H₃ O₂ QTBSBXVTEAMEQO-UHFFFAOYSA-M		Interactions Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain G [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain G [auth A]
NA Query on NA Download Ideal Coordinates CCD File SDF format, chain I [auth A] SDF format, chain K [auth A] SDF format, chain J [auth A] SDF format, chain H [auth A] SDF format, chain F [auth A] MOL2 format, chain I [auth A] MOL2 format, chain K [auth A] MOL2 format, chain J [auth A] MOL2 format, chain H [auth A] MOL2 format, chain F [auth A] mmCIF format, chain I [auth A] mmCIF format, chain K [auth A] mmCIF format, chain J [auth A] mmCIF format, chain H [auth A] mmCIF format, chain F [auth A]	F [auth A], H [auth A], I [auth A], J [auth A], K [auth A]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Interactions & Density Focus chain F [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free: 0.204 (Depositor), 0.210 (DCC)
R-Value Work: 0.174 (Depositor), 0.179 (DCC)
R-Value Observed: 0.176 (Depositor)

Space Group: I 4 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 151.092	α = 90
b = 151.092	β = 90
c = 92.179	γ = 90

Software Package:

Software Name	Purpose
HKL-3000	data collection
MLPHARE	phasing
REFMAC	refinement
HKL-3000	data reduction
HKL-3000	data scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2009-06-16

Deposition Author(s):

Wu, R.

Clancy, S.

Joachimiak, A.

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2009-06-16
Type: Initial release
Version 1.1: 2011-07-13
Changes: Advisory, Version format compliance
Version 1.2: 2024-11-20
Changes: Data collection, Database references, Derived calculations, Structure summary
