3H2L | pdb_00003h2l

Crystal structure of HCV NS5B polymerase in complex with a novel bicyclic dihydro-pyridinone inhibitor


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free:
    0.258 (Depositor), 0.260 (DCC)
  • R-Value Work:
    0.221 (Depositor), 0.224 (DCC)
  • R-Value Observed:
    0.222 (Depositor)

Starting Model: other
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 3H2L

Ligand Structure Quality Assessment


This is version 1.4 of the entry. See complete history

Literature

Discovery of tricyclic 5,6-dihydro-1H-pyridin-2-ones as novel, potent, and orally bioavailable inhibitors of HCV NS5B polymerase.

Ruebsam, F.Murphy, D.E.Tran, C.V.Li, L.S.Zhao, J.Dragovich, P.S.McGuire, H.M.Xiang, A.X.Sun, Z.Ayida, B.K.Blazel, J.K.Kim, S.H.Zhou, Y.Han, Q.Kissinger, C.R.Webber, S.E.Showalter, R.E.Shah, A.M.Tsan, M.Patel, R.A.Thompson, P.A.Lebrun, L.A.Hou, H.J.Kamran, R.Sergeeva, M.V.Bartkowski, D.M.Nolan, T.G.Norris, D.A.Khandurina, J.Brooks, J.Okamoto, E.Kirkovsky, L.

(2009) Bioorg Med Chem Lett 19: 6404-6412

  • DOI: https://doi.org/10.1016/j.bmcl.2009.09.045
  • Primary Citation Related Structures:
    3H2L

  • PubMed Abstract:

    A novel series of non-nucleoside small molecules containing a tricyclic dihydropyridinone structural motif was identified as potent HCV NS5B polymerase inhibitors. Driven by structure-based design and building on our previous efforts in related series of molecules, we undertook extensive SAR studies, in which we identified a number of metabolically stable and very potent compounds in genotype 1a and 1b replicon assays. This work culminated in the discovery of several inhibitors, which combined potent in vitro antiviral activity against both 1a and 1b genotypes, metabolic stability, good oral bioavailability, and high C(12) (PO)/EC(50) ratios.


  • Organizational Affiliation
    • Department of Medicinal Chemistry, Anadys Pharmaceuticals, Inc., 5871 Oberlin Drive, Suite 200, San Diego, CA 92121, USA. fruebsam@anadyspharma.com

Macromolecule Content

  • Total Structure Weight: 129.76 kDa
  • Atom Count: 9,246
  • Modeled Residue Count: 1,114
  • Deposited Residue Count: 1,156
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
NS5B polymerase
A, B
578Hepatitis C virus (isolate BK)Mutation(s): 1
EC: 2.7.7.48
UniProt
Find proteins for P26663 (Hepatitis C virus genotype 1b (isolate BK))
Explore P26663
Go to UniProtKB:  P26663
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP26663
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
YAK

Query on YAK



Download:Ideal Coordinates CCD File
C [auth A],
D [auth B]
N-{3-[(4aR,7aS)-1-(4-fluorobenzyl)-4-hydroxy-2-oxo-2,4a,5,6,7,7a-hexahydro-1H-cyclopenta[b]pyridin-3-yl]-1,1-dioxido-2H-1,2,4-benzothiadiazin-7-yl}methanesulfonamide
C23 H23 F N4 O6 S2
PAEBVIJMNXTTAT-AEFFLSMTSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free:  0.258 (Depositor), 0.260 (DCC)
  • R-Value Work:  0.221 (Depositor), 0.224 (DCC)
  • R-Value Observed: 0.222 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 86.548α = 90
b = 106.908β = 90
c = 126.575γ = 90
Software Package:
Software NamePurpose
HKL-2000data collection
EPMRphasing
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2009-12-08
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2021-10-13
    Changes: Database references, Derived calculations
  • Version 1.3: 2024-02-21
    Changes: Data collection
  • Version 1.4: 2024-04-03
    Changes: Refinement description
