3H1B | pdb_00003h1b

Crystal structure of EstE5, was soaked by isopropyl alcohol

PDB DOI: https://doi.org/10.2210/pdb3H1B/pdb

Classification: HYDROLASE
Organism(s): uncultured bacterium
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2009-04-11 Released: 2009-04-28
Deposition Author(s): Hwang, K.Y., Nam, K.H.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free:
0.295 (Depositor), 0.262 (DCC)
R-Value Work:
0.239 (Depositor), 0.247 (DCC)
R-Value Observed:
0.239 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 3H1B

This is version 1.2 of the entry. See complete history.

Literature

Crystal structure of EstE5, was soaked by organic solvent

Hwang, K.Y., Nam, K.H.

To be published.

Macromolecule Content

Total Structure Weight: 34.65 kDa
Atom Count: 2,261
Modeled Residue Count: 297
Deposited Residue Count: 322
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Esterase/lipase	A	322	uncultured bacterium	Mutation(s): 0 Gene Names: estE5 EC: 3.1.1
UniProt
Find proteins for A0ACD6B8B9 (uncultured bacterium) Explore A0ACD6B8B9 Go to UniProtKB: A0ACD6B8B9
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0ACD6B8B9
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free: 0.295 (Depositor), 0.262 (DCC)
R-Value Work: 0.239 (Depositor), 0.247 (DCC)
R-Value Observed: 0.239 (Depositor)

Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 61.307	α = 90
b = 61.307	β = 90
c = 150.144	γ = 90

Software Package:

Software Name	Purpose
HKL-2000	data collection
MOLREP	phasing
REFMAC	refinement
HKL-2000	data reduction
HKL-2000	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2009-04-28

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2009-04-28
Type: Initial release
Version 1.1: 2011-07-13
Changes: Advisory, Version format compliance
Version 1.2: 2023-11-01
Changes: Data collection, Database references, Refinement description
