3GOZ | pdb_00003goz

Crystal structure of the leucine-rich repeat-containing protein LegL7 from Legionella pneumophila. Northeast Structural Genomics Consortium target LgR148

PDB DOI: https://doi.org/10.2210/pdb3GOZ/pdb

Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
Organism(s): Legionella pneumophila subsp. pneumophila str. Philadelphia 1
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2009-03-20 Released: 2009-03-31
Deposition Author(s): Vorobiev, S.M., Abashidze, M., Seetharaman, J., Belote, R.L., Foote, E.L., Ciccosanti, C., Janjua, H., Xiao, R., Acton, T.B., Montelione, G.T., Hunt, J.F., Tong, L., Northeast Structural Genomics Consortium (NESG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free:
0.262 (Depositor), 0.264 (DCC)
R-Value Work:
0.205 (Depositor), 0.208 (DCC)
R-Value Observed:
0.208 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 1.3 of the entry. See complete history.

Literature

Crystal structure of the leucine-rich repeat-containing protein LegL7 from Legionella pneumophila. Northeast Structural Genomics Consortium target LgR148.

Vorobiev, S.M., Abashidze, M., Seetharaman, J., Belote, R.L., Foote, E.L., Ciccosanti, C., Janjua, H., Xiao, R., Acton, T.B., Montelione, G.T., Hunt, J.F., Tong, L.

To be published.

Macromolecule Content

Total Structure Weight: 39.53 kDa
Atom Count: 2,537
Modeled Residue Count: 320
Deposited Residue Count: 362
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Leucine-rich repeat-containing protein	A	362	Legionella pneumophila subsp. pneumophila str. Philadelphia 1	Mutation(s): 0 Gene Names: leg7, legL7, lpg2400
UniProt
Find proteins for Q5ZSW6 (Legionella pneumophila subsp. pneumophila (strain Philadelphia 1 / ATCC 33152 / DSM 7513)) Explore Q5ZSW6 Go to UniProtKB: Q5ZSW6
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q5ZSW6
Sequence Annotations Expand
Reference Sequence

Small Molecules

Modified Residues 1 Unique
ID	Chains	Modified Residue	Modification Type	Formula	2D Diagram
MSE Query on MSE	A	MET	Selenomethionine	C₅ H₁₁ N O₂ Se

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free: 0.262 (Depositor), 0.264 (DCC)
R-Value Work: 0.205 (Depositor), 0.208 (DCC)
R-Value Observed: 0.208 (Depositor)

Space Group: P 3₁ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 67.196	α = 90
b = 67.196	β = 90
c = 155.42	γ = 120

Software Package:

Software Name	Purpose
HKL-2000	data collection
SHELXDE	phasing
RESOLVE	model building
PHENIX	refinement
DENZO	data reduction
SCALEPACK	data scaling
RESOLVE	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2009-03-31

Deposition Author(s):

Northeast Structural Genomics Consortium (NESG)

Revision History (Full details and data files)

Version 1.0: 2009-03-31
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2017-10-25
Changes: Author supporting evidence
Version 1.3: 2024-11-20
Changes: Data collection, Database references, Derived calculations, Structure summary
