3GOH | pdb_00003goh

Crystal structure of alcohol dehydrogenase superfamily protein (NP_718042.1) from Shewanella oneidensis at 1.55 A resolution

• PDB DOI: https://doi.org/10.2210/pdb3GOH/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Shewanella oneidensis MR-1
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2009-03-19 Released: 2009-03-31
• Deposition Author(s): Joint Center for Structural Genomics (JCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.55 Å
• R-Value Free:
  0.203 (Depositor), 0.207 (DCC)
• R-Value Work:
  0.172 (Depositor), 0.180 (DCC)
• R-Value Observed:
  0.173 (Depositor)

Literature

Crystal structure of alcohol dehydrogenase superfamily protein (NP_718042.1) from Shewanella oneidensis at 1.55 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 35.28 kDa
• Atom Count: 2,630
• Modeled Residue Count: 297
• Deposited Residue Count: 315
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Alcohol dehydrogenase, zinc-containing	A	315	Shewanella oneidensis MR-1	Mutation(s): 0  Gene Names: NP_718042.1, SO_2452
UniProt
Find proteins for Q8EED0 (Shewanella oneidensis (strain ATCC 700550 / JCM 31522 / CIP 106686 / LMG 19005 / NCIMB 14063 / MR-1)) Explore Q8EED0  Go to UniProtKB:  Q8EED0

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
GOL	B [auth A], C [auth A]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.55 Å
• R-Value Free:  0.203 (Depositor), 0.207 (DCC)
• R-Value Work:  0.172 (Depositor), 0.180 (DCC)
• R-Value Observed: 0.173 (Depositor)

Diffraction Data: https://doi.org/10.18430/M33GOH

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 98.068	α = 90
b = 52.046	β = 95.29
c = 68.936	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PHENIX	refinement
SHELX	phasing
MolProbity	model building
XSCALE	data scaling
PDB_EXTRACT	data extraction
MAR345	data collection
XDS	data reduction
SHELXD	phasing
autoSHARP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2009-03-31
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Revision History

• Version 1.0: 2009-03-31
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Advisory, Source and taxonomy, Version format compliance
• Version 1.2: 2017-11-01
  Changes: Refinement description
• Version 1.3: 2019-07-24
  Changes: Data collection, Derived calculations, Refinement description
• Version 1.4: 2023-02-01
  Changes: Database references, Derived calculations
• Version 1.5: 2024-11-27
  Changes: Data collection, Structure summary
