3GJN | pdb_00003gjn

Following evolutionary paths to high affinity and selectivity protein-protein interactions using Colicin7 and Immunity proteins


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.48 Å
  • R-Value Free:
    0.276 (Depositor), 0.277 (DCC)
  • R-Value Work:
    0.242 (Depositor), 0.248 (DCC)
  • R-Value Observed:
    0.244 (Depositor)

Starting Models: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 3GJN

This is version 1.4 of the entry. See complete history

Literature

Following evolutionary paths to protein-protein interactions with high affinity and selectivity

Levin, K.B.Dym, O.Albeck, S.Magdassi, S.Keeble, A.H.Kleanthous, C.Tawfik, D.S.

(2009) Nat Struct Mol Biol 16: 1049-1055

  • DOI: https://doi.org/10.1038/nsmb.1670
  • Primary Citation Related Structures:
    3GJN

  • PubMed Abstract:

    How do intricate multi-residue features such as protein-protein interfaces evolve? To address this question, we evolved a new colicin-immunity binding interaction. We started with Im9, which inhibits its cognate DNase ColE9 at 10(-14) M affinity, and evolved it toward ColE7, which it inhibits promiscuously (Kd > 10(-8) M). Iterative rounds of random mutagenesis and selection toward higher affinity for ColE7, and selectivity (against ColE9 inhibition), led to an approximately 10(5)-fold increase in affinity and a 10(8)-fold increase in selectivity. Analysis of intermediates along the evolved variants revealed that changes in the binding configuration of the Im protein uncovered a latent set of interactions, thus providing the key to the rapid divergence of new Im7 variants. Overall, protein-protein interfaces seem to share the evolvability features of enzymes, that is, the exploitation of promiscuous interactions and alternative binding configurations via 'generalist' intermediates, and the key role of compensatory stabilizing mutations in facilitating the divergence of new functions.


  • Organizational Affiliation
    • Department of Biological Chemistry, Weizmann Institute of Science, Rehovot, Israel.

Macromolecule Content

  • Total Structure Weight: 51.88 kDa
  • Atom Count: 3,243
  • Modeled Residue Count: 403
  • Deposited Residue Count: 454
  • Unique protein chains: 2

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Colicin-E9 immunity protein
A, D
86Escherichia coliMutation(s): 7
Gene Names: immceiE9
UniProt
Find proteins for P13479 (Escherichia coli)
Explore P13479
Go to UniProtKB:  P13479
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP13479
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Colicin-E7
B, C
141Escherichia coliMutation(s): 1
Gene Names: colE7cea
EC: 3.1
UniProt
Find proteins for Q47112 (Escherichia coli)
Explore Q47112
Go to UniProtKB:  Q47112
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ47112
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.48 Å
  • R-Value Free:  0.276 (Depositor), 0.277 (DCC)
  • R-Value Work:  0.242 (Depositor), 0.248 (DCC)
  • R-Value Observed: 0.244 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 59.65α = 90
b = 53.713β = 105.59
c = 79.334γ = 90
Software Package:
Software NamePurpose
HKL-2000data collection
PHASESphasing
REFMACrefinement
HKL-2000data reduction
SCALEPACKdata scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2009-09-15
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2013-03-27
    Changes: Experimental preparation
  • Version 1.3: 2021-11-10
    Changes: Database references, Derived calculations
  • Version 1.4: 2023-11-01
    Changes: Data collection, Refinement description
