3GFF | pdb_00003gff

Crystal structure of IroE-like serine hydrolase (NP_718593.1) from SHEWANELLA ONEIDENSIS at 2.12 A resolution

• PDB DOI: https://doi.org/10.2210/pdb3GFF/pdb

• Classification: HYDROLASE
• Organism(s): Shewanella oneidensis
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2009-02-26 Released: 2009-03-10
• Deposition Author(s): Joint Center for Structural Genomics (JCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.12 Å
• R-Value Free:
  0.241 (Depositor), 0.240 (DCC)
• R-Value Work:
  0.184 (Depositor), 0.190 (DCC)
• R-Value Observed:
  0.187 (Depositor)

Literature

Crystal structure of IroE-like serine hydrolase (NP_718593.1) from SHEWANELLA ONEIDENSIS at 2.12 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: light scattering

Macromolecule Content

• Total Structure Weight: 76.09 kDa
• Atom Count: 5,305
• Modeled Residue Count: 632
• Deposited Residue Count: 662
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
IroE-like serine hydrolase	A, B	331	Shewanella oneidensis	Mutation(s): 0  Gene Names: NP_718593.1, SO_3025
UniProt
Find proteins for Q8ECU8 (Shewanella oneidensis (strain ATCC 700550 / JCM 31522 / CIP 106686 / LMG 19005 / NCIMB 14063 / MR-1)) Explore Q8ECU8  Go to UniProtKB:  Q8ECU8

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
IMD	D [auth A], F [auth B]	IMIDAZOLE C3 H5 N2 RAXXELZNTBOGNW-UHFFFAOYSA-O
CL	C [auth A], E [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.12 Å
• R-Value Free:  0.241 (Depositor), 0.240 (DCC)
• R-Value Work:  0.184 (Depositor), 0.190 (DCC)
• R-Value Observed: 0.187 (Depositor)

Diffraction Data: https://doi.org/10.18430/M33GFF

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 53.65	α = 90
b = 125.57	β = 117.94
c = 56.75	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PHENIX	refinement
SOLVE	phasing
MolProbity	model building
XSCALE	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction

Structure Validation

Entry History

Deposition Data

• Released Date: 2009-03-10
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Revision History

• Version 1.0: 2009-03-10
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Advisory, Version format compliance
• Version 1.2: 2017-10-25
  Changes: Author supporting evidence, Refinement description
• Version 1.3: 2019-07-24
  Changes: Data collection, Derived calculations, Refinement description
• Version 1.4: 2023-02-01
  Changes: Database references, Derived calculations
• Version 1.5: 2024-11-06
  Changes: Data collection, Refinement description, Structure summary
