3GED

Fingerprint and Structural Analysis of a Apo SCOR enzyme from Clostridium thermocellum


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free: 0.208
  • R-Value Work: 0.179
  • R-Value Observed: 0.180

Starting Models: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Sequence fingerprint and structural analysis of the SCOR enzyme A3DFK9 from Clostridium thermocellum.

Huether, R.Liu, Z.J.Xu, H.Wang, B.C.Pletnev, V.Z.Mao, Q.Duax, W.L.Umland, T.C.

(2010) Proteins 78: 603-613

  • DOI: https://doi.org/10.1002/prot.22584
  • Primary Citation of Related Structures:
    3GED, 3GEG

  • PubMed Abstract:

    We have identified a highly conserved fingerprint of 40 residues in the TGYK subfamily of the short-chain oxidoreductase enzymes. The TGYK subfamily is defined by the presence of an N-terminal TGxxxGxG motif and a catalytic YxxxK motif. This subfamily contains more than 12,000 members, with individual members displaying unique substrate specificities. The 40 fingerprint residues are critical to catalysis, cofactor binding, protein folding, and oligomerization but are substrate independent. Their conservation provides critical insight into evolution of the folding and function of TGYK enzymes. Substrate specificity is determined by distinct combinations of residues in three flexible loops that make up the substrate-binding pocket. Here, we report the structure determinations of the TGYK enzyme A3DFK9 from Clostridium thermocellum in its apo form and with bound NAD(+) cofactor. The function of this protein is unknown, but our analysis of the substrate-binding loops putatively identifies A3DFK9 as a carbohydrate or polyalcohol metabolizing enzyme. C. thermocellum has potential commercial applications because of its ability to convert biomaterial into ethanol. A3DFK9 contains 31 of the 40 TGYK subfamily fingerprint residues. The most significant variations are the substitution of a cysteine (Cys84) for a highly conserved glycine within a characteristic VNNAG motif, and the substitution of a glycine (Gly106) for a highly conserved asparagine residue at a helical kink. Both of these variations occur at positions typically participating in the formation of a catalytically important proton transfer network. An alternate means of stabilizing this proton wire was observed in the A3DFK9 crystal structures.


  • Organizational Affiliation

    Department of Structural Biology, SUNY at Buffalo, Buffalo, New York 14203, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Short-chain dehydrogenase/reductase SDR
A, B
247Acetivibrio thermocellus ATCC 27405Mutation(s): 0
Gene Names: Cthe_1510
UniProt
Find proteins for A3DFK9 (Acetivibrio thermocellus (strain ATCC 27405 / DSM 1237 / JCM 9322 / NBRC 103400 / NCIMB 10682 / NRRL B-4536 / VPI 7372))
Explore A3DFK9
Go to UniProtKB:  A3DFK9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA3DFK9
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
THJ
Query on THJ

Download Ideal Coordinates CCD File
D [auth A],
E [auth A],
H [auth B]
THIOSULFATE
O3 S2
DHCDFWKWKRSZHF-UHFFFAOYSA-L
GOL
Query on GOL

Download Ideal Coordinates CCD File
C [auth A],
G [auth B]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
NA
Query on NA

Download Ideal Coordinates CCD File
F [auth A],
I [auth B]
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free: 0.208
  • R-Value Work: 0.179
  • R-Value Observed: 0.180
  • Space Group: I 41 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 124.287α = 90
b = 124.287β = 90
c = 162.608γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
MOLREPphasing
PHENIXrefinement
PDB_EXTRACTdata extraction
HKL-2000data collection
HKL-2000data reduction
HKL-2000data scaling
AMoREphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2009-03-17
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Non-polymer description, Version format compliance
  • Version 1.2: 2017-11-01
    Changes: Refinement description
  • Version 1.3: 2023-09-06
    Changes: Data collection, Database references, Derived calculations, Refinement description
