Macromolecule Content

Total Structure Weight: 20.87 kDa
Atom Count: 1,186
Modelled Residue Count: 113
Deposited Residue Count: 157
Unique protein chains: 1

3GAN

Crystal structure of gene product from Arabidopsis thaliana At3g22680 with bound suramin

PDB DOI: 10.2210/pdb3GAN/pdb

Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
Organism(s): Arabidopsis thaliana
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2009-02-17 Released: 2009-03-03
Deposition Author(s): Burgie, E.S., Bingman, C.A., Wesenberg, G.E., Phillips Jr., G.N., Center for Eukaryotic Structural Genomics (CESG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free: 0.241
R-Value Work: 0.190
R-Value Observed: 0.192

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

Crystal structure of gene product from Arabidopsis thaliana At3g22680 with bound suramin

Burgie, E.S., Bingman, C.A., Wesenberg, G.E., Phillips Jr., G.N.

To be published.

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Uncharacterized protein At3g22680	A	157	Arabidopsis thaliana	Mutation(s): 0 Gene Names: At3g22680, At3g22680.1, MWI23.5, Q9LUJ3, Y3268_ARATH, RDM1
UniProt
Find proteins for Q9LUJ3 (Arabidopsis thaliana) Explore Q9LUJ3 Go to UniProtKB: Q9LUJ3
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q9LUJ3
Protein Feature View Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
SVR Query on SVR Download Ideal Coordinates CCD File SDF format, chain B [auth A] SDF format, chain C [auth A] MOL2 format, chain B [auth A] MOL2 format, chain C [auth A]	B [auth A], C [auth A]	8,8'-[CARBONYLBIS[IMINO-3,1-PHENYLENECARBONYLIMINO(4-METHYL-3,1-PHENYLENE)CARBONYLIMINO]]BIS-1,3,5-NAPHTHALENETRISULFON IC ACID C₅₁ H₄₀ N₆ O₂₃ S₆ FIAFUQMPZJWCLV-UHFFFAOYSA-N		Ligand Interaction
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain D [auth A] MOL2 format, chain D [auth A]	D [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Ligand Interaction

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free: 0.241
R-Value Work: 0.190
R-Value Observed: 0.192
Space Group: P 3₂ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 58.381	α = 90
b = 58.381	β = 90
c = 90.287	γ = 120

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
MOLREP	phasing
DM	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction
MAR345	data collection
HKL-2000	data reduction

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2009-03-03

Deposition Author(s):

Wesenberg, G.E.

Phillips Jr., G.N.

Center for Eukaryotic Structural Genomics (CESG)

Revision History (Full details and data files)

Version 1.0: 2009-03-03
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2017-11-01
Changes: Advisory, Refinement description
