3FKU

Crystal structure of influenza hemagglutinin (H5) in complex with a broadly neutralizing antibody F10


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.20 Å
  • R-Value Free: 0.286
  • R-Value Work: 0.232
  • R-Value Observed: 0.235

wwPDB Validation   3D Report Full Report


This is version 2.0 of the entry. See complete history


Literature

Structural and functional bases for broad-spectrum neutralization of avian and human influenza A viruses.

Sui, J.Hwang, W.C.Perez, S.Wei, G.Aird, D.Chen, L.M.Santelli, E.Stec, B.Cadwell, G.Ali, M.Wan, H.Murakami, A.Yammanuru, A.Han, T.Cox, N.J.Bankston, L.A.Donis, R.O.Liddington, R.C.Marasco, W.A.

(2009) Nat Struct Mol Biol 16: 265-273

  • DOI: https://doi.org/10.1038/nsmb.1566
  • Primary Citation of Related Structures:
    3FKU

  • PubMed Abstract:

    Influenza virus remains a serious health threat, owing to its ability to evade immune surveillance through rapid genetic drift and reassortment. Here we used a human non-immune antibody phage-display library and the H5 hemagglutinin ectodomain to select ten neutralizing antibodies (nAbs) that were effective against all group 1 influenza viruses tested, including H5N1 'bird flu' and the H1N1 'Spanish flu'. The crystal structure of one such nAb bound to H5 shows that it blocks infection by inserting its heavy chain into a conserved pocket in the stem region, thus preventing membrane fusion. Nine of the nAbs employ the germline gene VH1-69, and all seem to use the same neutralizing mechanism. Our data further suggest that this region is recalcitrant to neutralization escape and that nAb-based immunotherapy is a promising strategy for broad-spectrum protection against seasonal and pandemic influenza viruses.


  • Organizational Affiliation

    Department of Cancer Immunology & AIDS, Dana-Farber Cancer Institute, Harvard Medical School, 44 Binney Street JFB 826, Boston, Massachusetts 02115, USA. jianhua_sui@dfci.harvard.edu


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Hemagglutinin
A, C, E, G, I
A, C, E, G, I, K
338Influenza A virus (A/Viet Nam/1203/2004(H5N1))Mutation(s): 0
Gene Names: HA
UniProt
Find proteins for Q6J8F6 (Influenza A virus (strain A/Hong Kong/212/2003 H5N1 genotype Z+))
Explore Q6J8F6
Go to UniProtKB:  Q6J8F6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6J8F6
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Hemagglutinin
B, D, F, H, J
B, D, F, H, J, L
182Influenza A virus (A/Viet Nam/1203/2004(H5N1))Mutation(s): 0
Gene Names: HA
UniProt
Find proteins for Q6J8F6 (Influenza A virus (strain A/Hong Kong/212/2003 H5N1 genotype Z+))
Explore Q6J8F6
Go to UniProtKB:  Q6J8F6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6J8F6
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Neutralizing antibody F10280Homo sapiensMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 4
MoleculeChains Length2D Diagram Glycosylation3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
AA [auth a],
CA [auth c],
S [auth M],
U [auth O],
W [auth Q],
AA [auth a],
CA [auth c],
S [auth M],
U [auth O],
W [auth Q],
Y [auth V]
2N-Glycosylation
Glycosylation Resources
GlyTouCan:  G42666HT
GlyCosmos:  G42666HT
GlyGen:  G42666HT
Entity ID: 5
MoleculeChains Length2D Diagram Glycosylation3D Interactions
beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
BA [auth b],
DA [auth d],
T [auth N],
V [auth P],
X [auth R],
BA [auth b],
DA [auth d],
T [auth N],
V [auth P],
X [auth R],
Z [auth W]
3N-Glycosylation
Glycosylation Resources
GlyTouCan:  G15407YE
GlyCosmos:  G15407YE
GlyGen:  G15407YE
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.20 Å
  • R-Value Free: 0.286
  • R-Value Work: 0.232
  • R-Value Observed: 0.235
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 205.3α = 90
b = 118.5β = 99.6
c = 338.9γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
XSCALEdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

Revision History  (Full details and data files)

  • Version 1.0: 2009-02-24
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Advisory, Version format compliance
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Advisory, Atomic model, Data collection, Database references, Derived calculations, Structure summary
