3FIJ | pdb_00003fij

Crystal structure of a uncharacterized protein lin1909

• PDB DOI: https://doi.org/10.2210/pdb3FIJ/pdb

• Classification: structural genomics, unknown function
• Organism(s): Listeria innocua
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2008-12-11 Released: 2009-01-13
• Deposition Author(s): Sugadev, R., Burley, S.K., Swaminathan, S., New York SGX Research Center for Structural Genomics (NYSGXRC)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free:
  0.269 (Depositor), 0.270 (DCC)
• R-Value Work:
  0.217 (Depositor), 0.220 (DCC)
• R-Value Observed:
  0.217 (Depositor)

Literature

Crystal structure of a uncharacterized protein lin1909

Sugadev, R., Burley, S.K., Swaminathan, S.

To be published.

Biological Assembly 1

Global Symmetry: Dihedral - D4  (Explore in 3D)
Global Stoichiometry: Homo 8-mer - A8

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 228.52 kDa
• Atom Count: 14,467
• Modeled Residue Count: 1,783
• Deposited Residue Count: 2,032
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Lin1909 protein	A, B, C, D, E, F, G, H	254	Listeria innocua	Mutation(s): 0  Gene Names: lin1909
UniProt
Find proteins for Q92AL3 (Listeria innocua serovar 6a (strain ATCC BAA-680 / CLIP 11262)) Explore Q92AL3  Go to UniProtKB:  Q92AL3

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
MN	I [auth A], J [auth B], K [auth C], L [auth D], M [auth E], N [auth F], O [auth G], P [auth H]	MANGANESE (II) ION Mn WAEMQWOKJMHJLA-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B, C, D, E, F, G, H	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free:  0.269 (Depositor), 0.270 (DCC)
• R-Value Work:  0.217 (Depositor), 0.220 (DCC)
• R-Value Observed: 0.217 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 91.056	α = 90
b = 131.205	β = 108.79
c = 93.29	γ = 90

Software Package:

Software Name	Purpose
CBASS	data collection
SHELX	model building
SHARP	phasing
WARP	model building
CNS	refinement
HKL-2000	data reduction
HKL-2000	data scaling
SHELX	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2009-01-13
Deposition Author(s): Sugadev, R., Burley, S.K., Swaminathan, S., New York SGX Research Center for Structural Genomics (NYSGXRC)

Revision History

• Version 1.0: 2009-01-13
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Version format compliance
• Version 1.2: 2017-11-01
  Changes: Refinement description
• Version 1.3: 2021-02-10
  Changes: Database references, Derived calculations, Structure summary
• Version 1.4: 2024-11-27
  Changes: Data collection, Database references, Structure summary
