3F6V | pdb_00003f6v

Crystal structure of Possible transcriptional regulator for arsenical resistance

PDB DOI: https://doi.org/10.2210/pdb3F6V/pdb

Classification: transcription regulator
Organism(s): Rhodococcus jostii RHA1
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2008-11-06 Released: 2008-11-25
Deposition Author(s): Chang, C., Xu, X., Zheng, H., Savchenko, A., Edwards, A., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.48 Å
R-Value Free:
0.199 (Depositor), 0.220 (DCC)
R-Value Work:
0.159 (Depositor)
R-Value Observed:
0.161 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3F6V

This is version 1.3 of the entry. See complete history.

Literature

Crystal structure of Possible transcriptional regulator for arsenical resistance from Rhodococcus sp.

Chang, C., Xu, X., Zheng, H., Savchenko, A., Edwards, A., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 17.02 kDa
Atom Count: 972
Modeled Residue Count: 96
Deposited Residue Count: 151
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Possible transcriptional regulator, ArsR family protein	A	151	Rhodococcus jostii RHA1	Mutation(s): 0 Gene Names: RHA1_ro04124
UniProt
Find proteins for Q0S966 (Rhodococcus jostii (strain RHA1)) Explore Q0S966 Go to UniProtKB: Q0S966
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q0S966
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.48 Å
R-Value Free: 0.199 (Depositor), 0.220 (DCC)
R-Value Work: 0.159 (Depositor)
R-Value Observed: 0.161 (Depositor)

Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 42.106	α = 90
b = 42.106	β = 90
c = 104.219	γ = 90

Software Package:

Software Name	Purpose
SBC-Collect	data collection
HKL-3000	phasing
MLPHARE	phasing
DM	model building
SHELXD	phasing
RESOLVE	model building
Coot	model building
REFMAC	refinement
HKL-3000	data reduction
HKL-3000	data scaling
DM	phasing
RESOLVE	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2008-11-25

Deposition Author(s):

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2008-11-25
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2014-09-03
Changes: Refinement description
Version 1.3: 2023-12-27
Changes: Data collection, Database references, Derived calculations
