3F1Z

Crystal structure of putative nucleic acid-binding lipoprotein (YP_001337197.1) from Klebsiella pneumoniae subsp. pneumoniae MGH 78578 at 2.46 A resolution


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.46 Å
  • R-Value Free: 0.228
  • R-Value Work: 0.192

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

The structure of KPN03535 (gi|152972051), a novel putative lipoprotein from Klebsiella pneumoniae, reveals an OB-fold.

Das, D.Kozbial, P.Han, G.W.Carlton, D.Jaroszewski, L.Abdubek, P.Astakhova, T.Axelrod, H.L.Bakolitsa, C.Chen, C.Chiu, H.J.Chiu, M.Clayton, T.Deller, M.C.Duan, L.Ellrott, K.Elsliger, M.A.Ernst, D.Farr, C.L.Feuerhelm, J.Grzechnik, A.Grant, J.C.Jin, K.K.Johnson, H.A.Klock, H.E.Knuth, M.W.Krishna, S.S.Kumar, A.Marciano, D.McMullan, D.Miller, M.D.Morse, A.T.Nigoghossian, E.Nopakun, A.Okach, L.Oommachen, S.Paulsen, J.Puckett, C.Reyes, R.Rife, C.L.Sefcovic, N.Tien, H.J.Trame, C.B.van den Bedem, H.Weekes, D.Wooten, T.Xu, Q.Hodgson, K.O.Wooley, J.Deacon, A.M.Godzik, A.Lesley, S.A.Wilson, I.A.

(2010) Acta Crystallogr.,Sect.F 66: 1254-1260

  • DOI: 10.1107/S1744309109018168

  • PubMed Abstract:
  • KPN03535 (gi|152972051) is a putative lipoprotein of unknown function that is secreted by Klebsiella pneumoniae MGH 78578. The crystal structure reveals that despite a lack of any detectable sequence similarity to known structures, it is a novel vari ...

    KPN03535 (gi|152972051) is a putative lipoprotein of unknown function that is secreted by Klebsiella pneumoniae MGH 78578. The crystal structure reveals that despite a lack of any detectable sequence similarity to known structures, it is a novel variant of the OB-fold and structurally similar to the bacterial Cpx-pathway protein NlpE, single-stranded DNA-binding (SSB) proteins and toxins. K. pneumoniae MGH 78578 forms part of the normal human skin, mouth and gut flora and is an opportunistic pathogen that is linked to about 8% of all hospital-acquired infections in the USA. This structure provides the foundation for further investigations into this divergent member of the OB-fold family.


    Organizational Affiliation

    Stanford Synchrotron Radiation Lightsource, SLAC National Accelerator Laboratory, Menlo Park,California, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
putative nucleic acid-binding lipoprotein
A, B, C, D, E, F, G, H, I, J
133Klebsiella pneumoniae subsp. pneumoniae (strain ATCC 700721 / MGH 78578)Mutation(s): 0
Find proteins for A6TEE6 (Klebsiella pneumoniae subsp. pneumoniae (strain ATCC 700721 / MGH 78578))
Go to UniProtKB:  A6TEE6
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
PEG
Query on PEG

Download SDF File
Download CCD File
F, J
DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
MSE
Query on MSE
A, B, C, D, E, F, G, H, I, J
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

Unit Cell:
Length (Å)Angle (°)
a = 97.420α = 90.00
b = 105.507β = 90.00
c = 181.250γ = 90.00
Software Package:
Software NamePurpose
MolProbitymodel building
REFMACrefinement
SCALAdata scaling
SHELXDphasing
PHENIXrefinement
SHELXphasing
PDB_EXTRACTdata extraction
MOSFLMdata reduction
autoSHARPphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2008-11-18
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Advisory, Refinement description, Version format compliance
  • Version 1.2: 2017-10-25
    Type: Author supporting evidence, Refinement description
