3ERM | pdb_00003erm

The crystal structure of a conserved protein with unknown function from Pseudomonas syringae pv. tomato str. DC3000

PDB DOI: https://doi.org/10.2210/pdb3ERM/pdb

Classification: structural genomics, unknown function
Organism(s): Pseudomonas syringae pv. tomato
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2008-10-02 Released: 2008-10-21
Deposition Author(s): Tan, K., Zhou, M., Clancy, S., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.45 Å
R-Value Free:
0.269 (Depositor), 0.270 (DCC)
R-Value Work:
0.214 (Depositor), 0.215 (DCC)
R-Value Observed:
0.217 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3ERM

This is version 1.3 of the entry. See complete history.

Literature

The crystal structure of a conserved protein with unknown function from Pseudomonas syringae pv. tomato str. DC3000

Tan, K., Zhou, M., Clancy, S., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 50.64 kDa
Atom Count: 2,449
Modeled Residue Count: 318
Deposited Residue Count: 455
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
uncharacterized conserved protein	A, B, C, D, E	91	Pseudomonas syringae pv. tomato	Mutation(s): 0 Gene Names: Pseudomonas syringae pv. tomato, PSPTO1197, PSPTO_1197
UniProt
Find proteins for Q887T9 (Pseudomonas syringae pv. tomato (strain ATCC BAA-871 / DC3000)) Explore Q887T9 Go to UniProtKB: Q887T9
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q887T9
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain F [auth B] MOL2 format, chain F [auth B] mmCIF format, chain F [auth B]	F [auth B]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain F [auth B] Interactions & Density Focus chain F [auth B]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B, C, D, E	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.45 Å
R-Value Free: 0.269 (Depositor), 0.270 (DCC)
R-Value Work: 0.214 (Depositor), 0.215 (DCC)
R-Value Observed: 0.217 (Depositor)

Space Group: P 6₁ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 74.971	α = 90
b = 74.971	β = 90
c = 213.784	γ = 120

Software Package:

Software Name	Purpose
SBC-Collect	data collection
SHELXD	phasing
MLPHARE	phasing
DM	model building
RESOLVE	model building
HKL-3000	phasing
REFMAC	refinement
HKL-3000	data reduction
HKL-3000	data scaling
DM	phasing
RESOLVE	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2008-10-21

Deposition Author(s):

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2008-10-21
Type: Initial release
Version 1.1: 2011-07-13
Changes: Advisory, Refinement description, Version format compliance
Version 1.2: 2023-12-27
Changes: Data collection, Database references, Derived calculations
Version 1.3: 2024-11-13
Changes: Structure summary
