3D28

Crystal structure of hcv ns5b polymerase with a novel benzisothiazole inhibitor

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.313
  • R-Value Work: 0.257
  • R-Value Observed: 0.260

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history.


Literature

Structure-based design, synthesis, and biological evaluation of 1,1-dioxoisothiazole and benzo[b]thiophene-1,1-dioxide derivatives as novel inhibitors of hepatitis C virus NS5B polymerase.

Kim, S.H., Tran, M.T., Ruebsam, F., Xiang, A.X., Ayida, B., McGuire, H., Ellis, D., Blazel, J., Tran, C.V., Murphy, D.E., Webber, S.E., Zhou, Y., Shah, A.M., Tsan, M., Showalter, R.E., Patel, R., Gobbi, A., LeBrun, L.A., Bartkowski, D.M., Nolan, T.G., Norris, D.A., Sergeeva, M.V., Kirkovsky, L., Zhao, Q., Han, Q., Kissinger, C.R.

(2008) Bioorg Med Chem Lett 18: 4181-4185

  • DOI: https://doi.org/10.1016/j.bmcl.2008.05.083
  • Primary Citation of Related Structures:
    3D28, 3D5M

  • PubMed Abstract:

    • A novel series of HCV NS5B polymerase inhibitors comprising 1,1-dioxoisothiazoles and benzo[b]thiophene-1,1-dioxides were designed, synthesized, and evaluated. SAR studies guided by structure-based design led to the identification of a number of potent NS5B inhibitors with nanomolar IC(50) values ...

    A novel series of HCV NS5B polymerase inhibitors comprising 1,1-dioxoisothiazoles and benzo[b]thiophene-1,1-dioxides were designed, synthesized, and evaluated. SAR studies guided by structure-based design led to the identification of a number of potent NS5B inhibitors with nanomolar IC(50) values. The most potent compound exhibited IC(50) less than 10nM against the genotype 1b HCV polymerase and EC(50) of 70 nM against a genotype 1b replicon in cell culture. The DMPK properties of selected compounds were also evaluated.

    Organizational Affiliation:

    Anadys Pharmaceuticals, Inc., 3115 Merryfield Row, San Diego, CA 92121, USA. sdsunhee@yahoo.com



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
RNA-directed RNA polymerase
A, B
578Hepatitis C virus (isolate BK)Mutation(s): 1
EC: 2.7.7.48 (PDB Primary Data), 3.4.22 (UniProt), 3.4.21.98 (UniProt), 3.6.1.15 (UniProt), 3.6.4.13 (UniProt)
UniProt
Find proteins for P26663 (Hepatitis C virus genotype 1b (isolate BK))
Explore P26663
Go to UniProtKB:  P26663
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP26663
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
B34
Query on B34
Download Ideal Coordinates CCD File
C [auth A],
D [auth B]		(5S)-1-benzyl-3-(1,1-dioxido-1,2-benzisothiazol-3-yl)-4-hydroxy-5-(1-methylethyl)-1,5-dihydro-2H-pyrrol-2-one
C21 H20 N2 O4 S
XKOAFAIRGVAHRA-IBGZPJMESA-N		 Ligand Interaction
Binding Affinity Annotations
IDSourceBinding Affinity
B34 PDBBind:  3D28 IC50: 1400 (nM) from 1 assay(s)
Binding MOAD:  3D28 IC50: 1400 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.313
  • R-Value Work: 0.257
  • R-Value Observed: 0.260
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 83.979α = 90
b = 104.881β = 90
c = 126.008γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
CrystalCleardata collection
DENZOdata reduction
SCALEPACKdata scaling
EPMRphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


View more in-depth experimental data
Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2009-05-19
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2021-10-20
    Changes: Database references, Derived calculations
