3CS4

Structure-based design of a superagonist ligand for the vitamin D nuclear receptor


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.217
  • R-Value Work: 0.186
  • R-Value Observed: 0.186

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Structure-based design of a superagonist ligand for the vitamin d nuclear receptor.

Hourai, S.Rodrigues, L.C.Antony, P.Reina-San-Martin, B.Ciesielski, F.Magnier, B.C.Schoonjans, K.Mourino, A.Rochel, N.Moras, D.

(2008) Chem Biol 15: 383-392

  • DOI: 10.1016/j.chembiol.2008.03.016
  • Primary Citation of Related Structures:
    3CS4, 3CS6

  • PubMed Abstract:
  • Vitamin D nuclear receptor (VDR), a ligand-dependent transcriptional regulator, is an important target for multiple clinical applications, such as osteoporosis and cancer. Since exacerbated increase of calcium serum level is currently associated with VDR ligands action, superagonists with low calcium serum levels have been developed ...

    Vitamin D nuclear receptor (VDR), a ligand-dependent transcriptional regulator, is an important target for multiple clinical applications, such as osteoporosis and cancer. Since exacerbated increase of calcium serum level is currently associated with VDR ligands action, superagonists with low calcium serum levels have been developed. Based on the crystal structures of human VDR (hVDR) bound to 1alpha,25-dihydroxyvitamin D(3) and superagonists-notably, KH1060-we designed a superagonist ligand. In order to optimize the aliphatic side chain conformation with a subsequent entropy benefit, we incorporated an oxolane ring and generated two stereo diasteromers, AMCR277A and AMCR277B. Only AMCR277A exhibits superagonist activity in vitro, but is as calcemic in vivo as the natural ligand. The crystal structures of the complexes between the ligand binding domain of hVDR and these ligands provide a rational approach to the design of more potent superagonist ligands for potential clinical application.


    Organizational Affiliation

    Institut de Génétique et de Biologie Moléculaire et Cellulaire, Département de Biologie et de Génomique Structurales, Université Louis Pasteur, Strasbourg F-67000, France.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Vitamin D3 receptorA263Homo sapiensMutation(s): 0
Gene Names: VDRNR1I1
UniProt & NIH Common Fund Data Resources
Find proteins for P11473 (Homo sapiens)
Explore P11473
Go to UniProtKB:  P11473
PHAROS:  P11473
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
COV (Subject of Investigation/LOI)
Query on COV

Download Ideal Coordinates CCD File
B [auth A](1S,3R,5Z,7E,14beta,17alpha)-17-[(2S,4S)-4-(2-hydroxy-2-methylpropyl)-2-methyltetrahydrofuran-2-yl]-9,10-secoandrosta-5,7,10-triene-1,3-diol
C28 H44 O4
QFEREDUWILIRPI-VCQGKADLSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.217
  • R-Value Work: 0.186
  • R-Value Observed: 0.186
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 45.007α = 90
b = 51.37β = 90
c = 132.236γ = 90
Software Package:
Software NamePurpose
ADSCdata collection
CNSrefinement
HKL-2000data reduction
HKL-2000data scaling
CNSphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2008-05-27
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
